Featured FLEXTEK manuals
Flextek ECP-8180VE Service Manual
This manual describes the connector pin assignments and wiring details for the Flextek ECP-8180VE board. It is intended for technicians performing installation, troubleshooting, or service tasks.
The document lists power pins (e.g., +12 V on JP1, 5 V_SB on Pin 1), panel header signals (POWER LED, RESET, HDD LED, etc.), serial interfaces (RS‑232, RS‑422, RS‑485) and USB header pinouts. It also includes jumper settings for ATX power control and CMOS reset.
Covers: Connector Pinouts · Power Supply Connections · Panel Header Assignments · Serial Interface Pinouts · USB Header Pinout · Jumper Settings
FLEXTEK ECP-8580VE industrial 852GM low-power 5.25" CPU card Manual
The ECP-8580AVE is an industrial‑grade 5.25" CPU card built around an Intel 852GM chipset and an ultra‑low‑voltage Celeron M 600 MHz processor (optionally 900 MHz or Pentium M). It supports a DIMM slot for up to 1 GB DDR RAM, integrates an Intel Extreme Graphics controller with 64 MB shared video memory, and includes a range of interfaces such as MiniPCI, PC/104+, VGA, DVI and optional S‑Video.
The manual covers installation procedures, jumper configurations for TV output format, CMOS clear, watchdog function, and serial port modes, as well as detailed pin‑outs for all connectors (LVDS, panel, VGA, network, CompactFlash, USB, etc.). It also lists power requirements, operating temperature range, dimensions, and the accessories supplied with the card. This manual is written in Chinese.
Covers: Product Introduction · Technical Specifications · Physical and Environmental Parameters · Installation Guide · Jumper Settings · Interface Description
Latest FLEXTEK manuals
Flextek ECP-8180VE Service Manual
Service Manual 1 pages · 145 KB · ENFlextek ECP-8180VE Service Manual provides connector pinouts, power and USB assignments for quick installation.
FLEXTEK ECP-8580VE industrial 852GM low-power 5.25" CPU card Manual
User Manual 17 pages · 373 KB · ZHThe Flextek ECP-8580AVE industrial 5.25" CPU card manual provides specifications, installation steps, jumper settings, and interface details.
Which document do I need?
Service Manual
Disassembly, diagnostics and part numbers, for repair.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in FLEXTEK manuals
Which pins control the POWER LED?
POWER LED + is on Pin 2 and POWER LED – is on Pin 3.
What pins are used for the ATX power switch?
ATX POWER SWITCH – is on Pin 13 and ATX POWER SWITCH + is on Pin 14.
What processor does the ECP-8580AVE CPU card use?
It uses an ultra‑low‑voltage Celeron M 600 MHz processor, with optional 900 MHz or Pentium M versions.
From: FLEXTEK ECP-8580VE industrial 852GM low-power 5.25" CPU card Manual
How much DDR memory can the card support?
The card supports up to 1 GB of DDR RAM via its DIMM slot.
From: FLEXTEK ECP-8580VE industrial 852GM low-power 5.25" CPU card Manual
