Featured F14xxB manuals
Power Ocean F14xxB Series Filter User Manual
This manual describes the F14xxB series active filters, which are designed for ultra‑low‑frequency applications such as biomedical signal acquisition and precision instrumentation. It covers low‑pass, high‑pass, and band‑pass configurations with selectable cutoff frequencies from 0.1 Hz up to several megahertz.
The document includes detailed technical specifications, package dimensions, pin assignments, design equations for setting cutoff frequencies, and example circuits. It also provides tables of component values for Butterworth, Chebyshev, and other filter prototypes. This manual is written in Japanese.
Covers: Overview · Applications · Package Dimensions and Pin Assignment · Technical Specifications · Operation Method · Operation Example
Latest F14xxB manuals
Power Ocean F14xxB Series Filter User Manual
User Manual 6 pages · 177 KB · JAThe Power Ocean F14xxB series filter manual provides specifications, wiring, and setup instructions for low‑pass and band‑pass active filters.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in F14xxB manuals
What frequency range does the F14xxB filter cover?
The filter operates from 0.1 Hz up to 1 MHz, covering ultra‑low to high frequencies.
How is the cutoff frequency for a low‑pass filter calculated?
Set R3 = R4 = Rf2 and C3 = C4 = 0.01 µF, then use Fc = 1 / (2π Rf2 Cf).
