Featured Everlz manuals
everlz 7700R16x16-HD 7700R16x16-3G 16x16 SD/HD/3G Modular Router Manual
The 7700R16x16 is a compact 16x16 SD/HD/3G modular router designed for space‑constrained critical applications such as rack‑limited facilities or mobile installations. It fits into three slots of a standard Evertz 7700FR frame and includes an integrated controller with Q‑Link, dual serial ports, and an Ethernet port.
The router supports a wide range of video standards (SMPTE 292M, 258M, 310M, 424M, ASI) with up to 3 Gb/s bandwidth, automatic bit‑rate detection, and various control interfaces, including compatibility with Quartz remote panels and third‑party automation systems. Power is supplied by dual auto‑ranging 100‑240 V AC units with a consumption of 26 W.
Covers: Features & Benefits · Control Options · Technical Specifications · Power Supply · Ordering Information
Latest Everlz manuals
everlz 7700R16x16-HD 7700R16x16-3G 16x16 SD/HD/3G Modular Router Manual
User Manual 1 pages · 65 KB · ENThe Evertz 7700R16x16 modular router manual provides specifications, control options, and ordering information for the HD and 3G variants.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Everlz manuals
How many rack slots does the 7700R16x16 router occupy?
It uses only three slots of a traditional Evertz 7700FR frame.
From: everlz 7700R16x16-HD 7700R16x16-3G 16x16 SD/HD/3G Modular Router Manual
What control interfaces are built into the 7700R16x16 router?
It includes an internal Frame Controller with a single Q‑Link, dual serial ports, and an Ethernet port.
From: everlz 7700R16x16-HD 7700R16x16-3G 16x16 SD/HD/3G Modular Router Manual
