Key facts
- Manuals
- 5
- Languages
- ZH
- Last added
- 2011-12-16
Featured ENDEAVOUR manuals
ENDEAVOUR H50C4 Crimping Machine User Manual
The HYDRALOK H50C4 is a swaging (crimping) machine designed for hose and fitting assemblies. The manual describes the machine’s construction, technical specifications, and the procedures for both manual and automatic operation modes.
It also covers safety regulations, handling and transport, routine maintenance, lubrication, and detailed calibration steps, ensuring safe and reliable use throughout the warranty period. This manual is written in Chinese.
Covers: Warranty Conditions · Safety Regulations · Technical Data · Handling / Transport · Preliminary Checks · Routine Maintenance
ENDEAVOUR H32B4(SS) Hydralok Crimping Machine User Manual
The Hydralok H32B4(SS) is a swaging (crimping) machine designed for hydraulic hose assemblies. It features a 2.2 kW motor, a capacity of 3/16‑1 inches, and a compact 900 × 600 × 900 mm footprint.
The manual covers warranty conditions, conformity declaration, safety regulations, technical specifications, handling, preliminary checks, lighting, routine maintenance, detailed operating instructions, swaging charts, service procedures, calibration guidance, spare‑part lists, electrical diagrams and proper grease usage. This manual is written in Chinese.
Covers: Warranty Conditions · Declaration of Conformity · Safety Regulations · Technical Data · Handling / Transport · Preliminary Checks
Endeavour H25MM HYDRALOK Crimping Machine User Manual
This manual covers the HYDRALOK H25MM crimping machine produced by Endeavour International Ltd. It includes warranty information, safety regulations, technical specifications, handling instructions, and detailed operating procedures.
Additional sections describe routine maintenance, spare parts, optional air/hydraulic power packs, and proper lubrication methods to ensure reliable performance. This manual is written in Chinese.
Covers: Warranty Conditions · Safety Regulations · Technical Data · Handling/Transport · Routine Maintenance · Operating Instructions
Endeavour H25ME Crimping Machine User Manual
This manual covers safety regulations, handling, technical specifications and routine maintenance for the Endeavour H25ME crimping machine. It includes detailed operating instructions, calibration procedures, and spare‑part information.
The document also outlines warranty conditions, optional air/hydraulic power pack options, and proper use of greases and hydraulic oil for reliable performance. This manual is written in Chinese.
Covers: Warranty Conditions · Declaration of Conformity · Safety Regulations · Technical Data · Handling / Transport · Preliminary Checks
Latest ENDEAVOUR manuals
ENDEAVOUR Int.Ltd Compak1 HYDRALOK Crimping machine Manual
ENDEAVOUR H50C4 Crimping Machine User Manual
User Manual 18 pages · 379 KB · ZHThe ENDEAVOUR H50C4 crimping machine user manual provides safety regulations, technical data, operating instructions, maintenance and calibration guidance.
ENDEAVOUR H32B4(SS) Hydralok Crimping Machine User Manual
User Manual 22 pages · 595 KB · ZHThe ENDEAVOUR H32B4(SS) Hydralok crimping machine user manual provides safety rules, technical data, operation steps, maintenance, calibration and…
Endeavour H25MM HYDRALOK Crimping Machine User Manual
User Manual 20 pages · 270 KB · ZHThe Endeavour H25MM HYDRALOK crimping machine user manual provides safety rules, technical data, operating instructions and maintenance guidance.
Endeavour H25ME Crimping Machine User Manual
User Manual 18 pages · 347 KB · ZHThe Endeavour H25ME Hydralok crimping machine user manual provides safety rules, technical data, operation steps and maintenance guidance.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ENDEAVOUR manuals
What is the warranty period for the H50C4 machine?
The machine is warranted for twelve (12) months starting from the date of delivery.
What voltage options does the H50C4 support?
It can operate on 220/240‑1‑50 Hz or 220/240‑380/440‑3‑50 Hz power supplies.
What is the warranty period for the HYDRALOK H25MM?
The machine is warranted for 12 months starting from the date of delivery to the customer.
How often should the oil level be checked?
A monthly check of the oil level in the pump is recommended for machines in regular use.
What is the warranty period for the H25ME machine?
The machine is warranted for 6 months from the date of delivery.
What is the maximum noise level of the machine?
The noise level does not exceed 70 dB.
