Featured EE21 manuals
Sensor Technology EE21 Series Transmitter User Manual
The EE21 series transmitter measures relative temperature and relative humidity with high accuracy. It can be installed on walls or in pipes using an insert‑type connector, and offers selectable voltage or current output signals.
The manual includes electrical connection guidelines, protection ratings, cable length recommendations, and details on sensor elements (HC1000 humidity sensor and Pt1000 temperature sensor). Power supply options cover both DC and AC ranges, and typical power consumption is listed for each mode. This manual is written in Chinese.
Covers: Measurement Range · Accuracy · Output Options · Power Supply · Installation Methods · Electrical Connection
Latest EE21 manuals
Sensor Technology EE21 Series Transmitter User Manual
User Manual 2 pages · 211 KB · ZHThe Sensor Technology EE21 series transmitter manual provides specifications, installation options, and wiring details for temperature and humidity measurement.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in EE21 manuals
What is the humidity measurement range of the EE21 transmitter?
The EE21 transmitter measures humidity from 0 %RH to 100 %RH.
