Featured Echelon manuals
Echelon LonWorks Power Line Data Acquisition System
The article describes a three‑phase data‑collection system that uses power lines as the communication medium. It leverages LonWorks fieldbus technology, developed by Echelon, to enable reliable data transfer over low‑voltage power networks.
The system architecture consists of data nodes, a concentrator, a router, a modem and a remote PC. Key components include the PLT‑22 power‑line transceiver, the Neuron3150 communication chip, and the RTR‑10 router core module, which together provide dual‑band carrier transmission, noise mitigation, and inter‑subnet routing. This manual is written in Chinese.
Covers: Abstract · Keywords · Introduction · Power Line Communication · System Design · Data Nodes and Concentrator
Echelon LPR-10 Router Module 42100R, 42101R, 42102R, 42103R, 42104R, 42105R User Manual
The manual describes the Echelon LPR-10 router module, a dual‑channel LONWORKS router that supports TP/FT-10, TP/XF-78 and TP/XF-1250 channels. It features a dual‑chip Neuron 3150 processor, hot‑swap capability, and compliance with UL, cUL, CE, FCC and RoHS certifications.
Installation instructions cover mounting the module in 2‑type or 2D DIN bases, wiring via screw terminals, and using the front‑panel connectors. The document also lists performance specifications, ordering information, and references to additional Echelon documentation. This manual is written in Chinese.
Covers: Features · Function · Installation · Performance Specifications · Documentation · Ordering Information
Echelon Industrial Ethernet and ANSI 709 Manual
This document explains how Echelon combines industrial Ethernet with the ANSI 709.1 open, interoperable, distributed‑control architecture. It describes the benefits of using non‑shielded twisted‑pair cabling, low‑cost nodes and a client‑server management system to achieve reliable, low‑cost networking for sensors, actuators and controllers.
The paper also compares typical industrial Ethernet implementations with ANSI 709.1/709.3 physical layers, outlines network configuration tools, and provides example routing solutions that support both peer‑to‑peer and master‑slave communication over TCP/IP. This manual is written in Chinese.
Covers: Industrial Ethernet and ANSI 709 Overview · Network Configuration and Installation Tools · ANSI709 and TCP/IP Integration · Typical Differences between Industrial Ethernet and ANSI709 · Summary
Latest Echelon manuals
Echelon LonWorks Power Line Data Acquisition System
Other 3 pages · 31 KB · ZHThis paper presents a three‑phase power‑line data acquisition system using Echelon LonWorks technology with PLT‑22 transceivers and RTR‑10 routers.
Echelon LPR-10 Router Module 42100R, 42101R, 42102R, 42103R, 42104R, 42105R User Manual
User Manual 3 pages · 250 KB · ZHThe Echelon LPR-10 router module manual provides specifications, installation, and operation details for models 42100R‑42105R.
Echelon Industrial Ethernet and ANSI 709 Manual
Application Note 8 pages · 411 KB · ZHTechnical overview of Echelon's industrial Ethernet solution based on the ANSI 709.1 protocol.
ECHELON 74501 74502 74503 And7450 net adapter Manual
