Featured DETRON manuals
DETRON DIM Series Power Supply User Manual
This manual covers the safe operation of DETRON DIM series power supplies. It begins with safety warnings, explains the meaning of each connector, and provides step‑by‑step wiring methods for both single‑unit and parallel/series configurations.
Later sections describe the functional protections (over‑voltage, over‑current, over‑temperature), insulation and dielectric test requirements, installation recommendations, cable and fuse specifications, fan maintenance, and troubleshooting procedures to verify proper operation before service. This manual is written in Chinese.
Covers: Safety Warnings · Connector Description · Wiring Method · Function and Protection · Insulation / Dielectric Test · Installation Guidelines
DETSON IM101-5 Switching Power Supply Datasheet
The DETSON IM101-5 is a compact 100 W switching power supply designed for AC‑DC conversion. It accepts an input voltage of AC 220 V (110 V) ±20% and operates over a frequency range of 47‑63 Hz. The unit delivers a regulated 24 V output at up to 4.2 A with a typical efficiency of 75 % (maximum 80 %).
The datasheet provides full electrical specifications, protection features such as overload and short‑circuit shutdown after 2 s, response time of 1 ms for load changes, and environmental limits including an operating temperature range of –10 °C to +50 °C. Mechanical dimensions, weight (0.8 kg), and compliance with VDE, FCC, GB4943, UL1950, IEC380 standards are also listed. This manual is written in Chinese.
Covers: Technical Specifications · Electrical Characteristics · Protection Features · Environmental Ratings · Mechanical Dimensions
Latest DETRON manuals
DETRON DIM Series Power Supply User Manual
User Manual 14 pages · 295 KB · ZHThe DETRON DIM series power supply user manual provides safety warnings, wiring instructions, functional descriptions, protection features, and installation…
DETRON DIS100-5 AC-DC power supply Manual
DETSON IM101-5 Switching Power Supply Datasheet
Datasheet 1 pages · 72 KB · ZHThe DETSON IM101-5 is a 100 W AC‑DC switching power supply with up to 80 % efficiency and detailed technical specifications.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in DETRON manuals
What is the input voltage range for the DIM series power supplies?
The input voltage must be between 85 V and 265 V AC at 47 – 63 Hz.
How is over‑current protection triggered?
Over‑current protection activates when the output current exceeds 105 % of the average rated output current.
What is the input voltage range of the IM101-5?
The unit accepts AC 220 V (110 V) with a tolerance of ±20 %.
What is the maximum efficiency of the IM101-5?
The power supply can reach up to 80 % efficiency, with a typical value of 75 %.
