Featured DCT manuals
DCT JG Differential Pressure Gauge User Manual
The DCT JG is a hand‑held differential pressure gauge built with stainless‑steel construction and a 4‑digit LCD display. It offers high/low pressure capture with an update rate of three times per second and includes optional NEMA‑4 housing and accessories such as pressure adapters and mounting rings.
The manual details the gauge's specifications, power options (9 V battery, AC adapter, or DC supply), selectable pressure ranges from 0‑1 psi up to 0‑10,000 psi, and safety limits. It also lists order codes for accessories, electrical connection options, and optional units of measure.
Covers: Overview · Specifications · Power Options · Pressure Range · Accessories · Order Codes
Latest DCT manuals
DCT Digital Force Indicator Model LC Ranges to 50 000 lbs. Compression Measurement High/Low Force Capture Manual
The Model LC Digital Force Indicator is a highly portable force measurement device. With its 9V battery supply and compact size the indicator can easily be carried to remote locations to perform force measurement calibrations. The unit can measure compression forces up to 50,000 lbs. The peak capture feature allows the highest force reading taken to be displayed with the push of a button. A zero/tare button is also standard on all models. The remote location of the load sensor minimizes the chance of damage to the electronic body of the gauge. The stainless steel construction of the sensor and the indicator makes them resistant to the occasional mishandling than can occur in the field. Optional handles are available for the load cell and gauge. See our web site for more information.
DCT JG Differential Pressure Gauge User Manual
User Manual 3 pages · 171 KB · ENThe DCT JG differential pressure gauge manual provides specifications, operation instructions, and accessory information for the hand‑held device.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in DCT manuals
What is the accuracy of the DCT JG gauge?
The gauge has an accuracy of 0.296 FS.
What power sources can be used with the JG gauge?
It can be powered by one or two 9 V alkaline batteries, a 110 V AC adapter, or an 11‑32 VDC supply.
