Key facts
- Manuals
- 2
- Languages
- EN
- Last added
- 2012-01-04
Featured DCM manuals
XP Power DCM Series DC-DC Converter Datasheet
This document describes the DCM family of open‑frame telecom DC‑DC converters, covering both +48 VDC and -48 VDC input configurations. It includes detailed electrical specifications such as input/output voltage ranges, efficiency, switching frequency, and isolation ratings.
Mechanical drawings, thermal considerations, environmental limits, and safety agency approvals are also provided, along with EMC test results and service‑life estimations. The data sheet is intended for designers integrating the DCM modules into networking, routing, and video production equipment.
Covers: General Specifications · Input Characteristics · Output Characteristics · Mechanical Details · Thermal Considerations · EMC – Immunity and Emissions
XP Power DCM Series Product Leaflet
This leaflet describes the DCM family of open‑frame telecom DC‑DC converters, covering both the DCM60 and DCM100 models. It outlines input options (48 VDC or –48 VDC), output ratings, and key performance figures such as efficiency and switching frequency.
Additional sections detail mechanical dimensions, thermal limits, electromagnetic compatibility, and the various safety certifications (UL, CSA, CE, etc.) that the converters meet, along with contact information for XP Power worldwide sales offices.
Covers: Models and Ratings · Input Characteristics · Output Characteristics · General Specifications · Mechanical Details · Thermal Considerations
Latest DCM manuals
XP Power DCM Series DC-DC Converter Datasheet
Datasheet 8 pages · 1.2 MB · ENThe XP Power DCM Series datasheet provides specifications, electrical characteristics, mechanical dimensions, and safety approvals for the DCM DC‑DC converters.
XP Power DCM Series Product Leaflet
Product Leaflet 8 pages · 1.2 MB · ENThe XP Power DCM Series product leaflet provides specifications, mechanical dimensions, thermal considerations, and safety approvals for the DCM DC‑DC…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in DCM manuals
What input voltage range can the DCM series accept?
The DCM series can be configured for either +48 VDC or -48 VDC input.
What is the efficiency at full load?
The DCM series achieves 85 % efficiency at full load.
What input voltage configurations are supported by the DCM series?
The DCM converters can operate from a 36 VDC input and can be configured for either +48 VDC or –48 VDC telecom input.
What is the efficiency of the DCM converters at full load?
The converters achieve an efficiency of 85 % at full load.
