Featured DAT manuals
DA&T U1/U2 Audio Interface Specification Sheet
This document lists the key technical specifications of the DA&T U1/U2 audio interface, including supported audio formats, sample rates, and bit depths. It also covers the USB interface capabilities and power supply requirements.
Physical characteristics such as dimensions and connector types are provided, allowing users to assess compatibility with their studio setups and equipment. This manual is written in Japanese.
Covers: Audio Specifications · USB Interface · Power Requirements · Physical Dimensions · Performance Parameters
Botron B8572 Resistance Tester Operating Instructions
The Botron B8572 is a rugged resistance tester capable of insulation, static, continuity, and ordinary resistance measurements. It offers selectable test voltages from 10 V to 500 V and a range of measurement modes to suit various industry standards.
The manual explains how to power on the device, select test modes by rotating the knob, configure test time and current limits, and interpret results. It also includes details on the point‑to‑point heavy‑hammer electrodes, battery requirements, and warranty terms. This manual is written in Chinese.
Covers: Product Description · Test Modes Overview · Insulation / Static Resistance Test · Continuity Test · Ordinary Resistance Test · Settings and Controls
Latest DAT manuals
DA&T U1/U2 Audio Interface Specification Sheet
Product Leaflet 4 pages · 545 KB · JAThe DA&T U1/U2 audio interface specification sheet provides technical details such as sample rates, bit depth, USB connectivity, power requirements and…
Botron B8572 Resistance Tester Operating Instructions
User Manual 5 pages · 362 KB · ZHThe Botron B8572 resistance tester manual provides usage instructions, test modes, specifications, and safety information.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in DAT manuals
What is the maximum audio sample rate of the DA&T U1/U2?
The device supports up to 192 kHz sample rate at 24‑bit resolution.
What USB audio format does the DA&T U1/U2 provide?
It provides USB audio at 96 kHz with 24‑bit depth.
How do I select the test mode on the B8572?
Rotate the knob to the voltage selection area to start insulation/static mode, to the “Ω” position for continuity mode, or to the “kΩ” position for ordinary resistance mode; turn to “OFF” to power off.
What is the default test time for insulation or static resistance measurements?
If no test time is selected, the device uses the default “即时” (InS) mode, requiring the user to hold the TEST key continuously until the measurement finishes.
