Featured Current manuals
Current HY 5-P to 25-P Current Transducers Datasheet
The Current HY series are Hall‑effect current transducers offering galvanic isolation between the high‑power primary circuit and the low‑power secondary electronics. They provide a compact PCB‑mountable design, low power consumption and a wide measuring range from 5 A up to 25 A.
Key features include 2500 V isolation, ±5 % supply voltage tolerance, high accuracy, fast response (<3 µs) and compliance with EN 50178. Typical applications are general‑purpose inverters, AC variable‑speed drives, static converters for DC motor drives, UPS and SMPS systems.
Covers: Electrical Data · Features · Advantages · Applications · Mechanical Dimensions · Pin Arrangement
Kohshin Electric Current Sensors User Manual
This manual provides detailed instructions for the use, installation, and maintenance of Kohshin Electric current sensors, covering the HC, HD, HS, HM, and HA‑BR series. It includes safety warnings, recommended wiring practices, and guidelines for handling and soldering the devices.
The document also lists the electrical characteristics, performance limits, and environmental specifications for each sensor type, along with export and usage limitations for special applications.
Covers: Introduction · Instruction for Use · Safety Precautions · Wiring and Installation · Characteristics · Product Marking
Latest Current manuals
Current HY 5-P to 25-P Current Transducers Datasheet
Datasheet 19 pages · 276 KB · ENTechnical data sheet for Current HY series Hall‑effect current transducers covering 5 A to 25 A.
Kohshin Electric Current Sensors User Manual
User Manual 107 pages · 4.3 MB · ENInstallation and usage instructions for Kohshin Electric current sensor series, including safety, wiring, and performance specifications.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Current manuals
What measuring principle is used in the HY series transducers?
They use the Hall‑effect measuring principle.
What is the isolation voltage between primary and secondary circuits?
The transducers provide 2500 V isolation.
What capacitor should be connected between the control power supply and ground?
A capacitor of approximately 0.1 µF should be connected between the control power supply and GND.
What are the recommended soldering temperatures for flow and hand soldering?
Flow solder: about 250 °C for 5 seconds; Hand solder: about 280‑300 °C for 3 seconds (Pb‑free flow solder: 260 °C for 5 seconds; Pb‑free hand solder: 340 °C for 4 seconds).
