Featured CrossPoint manuals
Extron CrossPoint 450 Plus Series Matrix Switcher Manual
The CrossPoint 450 Plus series is an ultra‑wideband RGB and stereo‑audio matrix switcher designed for high‑resolution computer video and audio routing systems. It offers lossless switching between sources with advanced digital synchronization (ADSP) and Ethernet monitoring (IP Link).
Key features include 450 MHz video bandwidth, up to 130 MHz flat response, RS‑232/RS‑422 and RJ‑45 Ethernet control ports, optional redundant power, and rack‑mountable chassis ranging from 8U to 30U. Detailed technical specifications, installation guidelines, and control options are provided throughout the manual. This manual is written in Chinese.
Covers: Introduction · Common Features · Technical Specifications · Control and Remote Interfaces · Power and Redundant Power · Installation and Rack Mounting
Latest CrossPoint manuals
Extron CrossPoint 450 Plus Series Matrix Switcher Manual
User Manual 4 pages · 1.6 MB · ZHThe Extron CrossPoint 450 Plus series matrix switcher manual provides specifications, features, and installation instructions for ultra‑wideband RGB and…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in CrossPoint manuals
What is the video bandwidth of the CrossPoint 450 Plus matrix switcher?
It provides a 450 MHz (-3 dB) video bandwidth at full load.
From: Extron CrossPoint 450 Plus Series Matrix Switcher Manual
