BM Semiconductor BM1410A 2A DC/DC Application Note
The document provides a detailed guide for designing circuits with the BM1410A DC/DC converter. It describes each pin’s purpose, recommended external components, and practical PCB layout tips to achieve low ripple and stable operation.
Key recommendations include placing input and output capacitors close to the IC, using inductors of 22‑68 µH, selecting diodes rated at 1.5 × the maximum output current, and following the special notes for low‑voltage applications and alternative part substitutions. This manual is written in Chinese.
Covers: Boost Pin (Pin 1) · Input Pin (Pin 2) · SW Output Pin (Pin 3) · Ground Pin (Pin 4) · Reference Voltage Pin (Pin 5) · Compensation Pin (Pin 6)
Latest BM manuals
BM PCI AUDIO ADAPTER USER S GUIDE
The IBM PCI AUDIO ADAPTER provides the next generation of PCI audio performance to the PC market. The adapter not only meets the new demands of advanced PC audio applications but also enables the integration of a complete multimedia subsystem on a single adapter.
BM SPSS Statistics 20 Core System user manual
This file is the user manual of IBM SPSS Statistics 20, which introduces the features of the software
BM Semiconductor BM1410A 2A DC/DC Application Note
Application Note 2 pages · 97 KB · ZHThis application note explains how to use the BM1410A 2 A DC/DC converter, covering pin functions, component selection, and layout recommendations.
Which document do I need?
Application Note
How to use the product for one specific task, with worked examples.
Questions answered in BM manuals
What is the recommended input voltage range for the BM1410A?
The input voltage should be between +6.5 V and +20 V.
What reference voltage does the BM1410A use?
It uses a 1.22 V reference voltage.
