Basiq models by category
Featured Basiq manuals
Antec Basiq BP430 Power Supply User Manual
The BP430 is an Antec Basiq series power supply that complies with the ATX12V v2.2 standard and features dual 12 V output rails, universal 100‑240 V input, and active PFC for improved power factor. It includes protection circuits such as over‑current (OCP), over‑voltage (OVP) and short‑circuit (SCP) protection.
The manual explains how to safely install the unit, connect the 24‑pin main power connector (or the optional 20‑pin configuration), attach peripheral connectors (SATA, video‑card, optical drive, etc.), and operate the power switch. It also provides customer‑support contact information for the United States and Europe. This manual is written in Japanese.
Covers: Power Switch · Installation Procedure · Main Power Connector · Peripheral Connectors · Safety Protections
Antec Basiq BP430 User Manual
The Basiq BP430 is an ATX12V version 2.2 compliant power supply that delivers two 12 V output circuits and includes protective circuitry such as Over‑Current, Over‑Voltage, and Short‑Circuit protection. It features a universal 100‑240 V input with Active Power Factor Correction for efficient operation.
The manual explains how to safely install the unit, connect the 24‑pin (or 20‑pin) main power connector, attach the 4‑pin 12 V connector, and hook up peripheral devices. It also describes the main power switch operation, which includes a soft on/off feature that allows the computer case switch to control power.
Covers: Product Overview · Safety and Protection Features · Power Switch Operation · Installation Procedure · Connector Guide · Technical Specifications
Basiq BP550 PLUS Power Supply User Manual
The BP550 PLUS is an ATX12V 2.2‑compliant power supply designed by Basiq. It operates from a universal 100‑240 V input, features active PFC for improved power factor, and includes protection circuits such as OVP, OCP and SCP to ensure safe operation.
The manual details the installation procedure, including disconnecting existing power sources, connecting the 24‑pin main power connector and the 4‑pin 12 V connector, and configuring the unit for 20‑pin motherboards when necessary. Connector pinouts and wiring diagrams are provided for both ATX and PCI‑Express connections.
Covers: Safety and Protection Features · Installation Steps · Connector Pinout · Power Supply Compatibility · Technical Specifications
Latest Basiq manuals
Antec Basiq BP430 Power Supply User Manual
User Manual 4 pages · 187 KB · JAThe Antec Basiq BP430 User Manual provides installation, connection, and safety instructions for this ATX12V 2.2 compliant power supply.
Antec Basiq BP430 User Manual
User Manual 4 pages · 140 KB · ENThe Antec Basiq BP430 User Manual provides installation steps, safety features, and specifications for the ATX12V 2.2 power supply.
Basiq BP550 PLUS Power Supply User Manual
User Manual 5 pages · 228 KB · ENThe Basiq BP550 PLUS Power Supply User Manual provides installation, wiring, and safety instructions for the ATX12V 2.2 compliant unit.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Basiq manuals
How do I turn on the power switch?
Make sure the power switch is set to the ON (1) position before powering the computer; normally you do not need to switch it OFF during regular use.
What protection features are included?
The BP430 includes over‑current (OCP), over‑voltage (OVP) and short‑circuit (SCP) protection circuits.
How do I turn on the power supply?
Turn the main power switch to the ON (I) position before you boot up the computer.
How can I connect the power supply to a 20‑pin motherboard?
Detach the 4‑pin attachment on the 24‑pin connector and use the remaining pins.
What protection circuits are included in the BP550 PLUS?
The unit includes over‑voltage protection (OVP), over‑current protection (OCP) and short‑circuit protection (SCP).
How many pins does the main power connector have?
The main power connector is a 24‑pin connector.
