Featured AUTN-CYG60 manuals
AUTN CYG60 Series Micro Pressure Sensor Transmitter Manual
The AUTN CYG60 series is a miniature pressure sensor transmitter designed for high‑precision measurements in research, biomedical, fluid dynamics, and other scientific applications. It features a compact package, low temperature drift, and robust construction suitable for harsh environments.
The document lists performance parameters such as measurement range (0 kPa to 6 MPa), supply voltage (10–24 VDC), output options (1.5–4.5 mV/V, 4–20 mA, 0–5 VDC), and operating temperature limits. It also includes installation notes, physical dimensions, and optional functions for customized solutions. This manual is written in Chinese.
Covers: Product Overview · Features · Performance Parameters · Measurement Range · Signal Output · Physical Dimensions
Latest AUTN-CYG60 manuals
AUTN CYG60 Series Micro Pressure Sensor Transmitter Manual
Product Leaflet 2 pages · 114 KB · ZHThe AUTN CYG60 series micro pressure sensor transmitter manual provides specifications, operating ranges, and installation guidelines.
Questions answered in AUTN-CYG60 manuals
What is the measurement range of the AUTN CYG60 series sensor?
It can measure pressures from 0 kPa up to 6 MPa, covering ranges such as 0–10 kPa and 20 kPa.
From: AUTN CYG60 Series Micro Pressure Sensor Transmitter Manual
What supply voltage does the sensor require?
The sensor operates from 10 VDC to 24 VDC, with a typical value of 15 VDC.
From: AUTN CYG60 Series Micro Pressure Sensor Transmitter Manual
