Featured AT-WR54BG manuals
AT-WR54BG 802.11g Turbo Mode 108Mbps AT-WR54BG high-speed 108Mbps Wireless Turbo mode network card Manual
The AT‑WR54BG is a CardBus wireless network adapter that supports IEEE 802.11b/g standards and offers a Turbo mode delivering up to 108 Mbps data rate. It operates in the 2.4 GHz ISM band and provides multiple security options including WEP (64‑, 128‑, 152‑bit), WPA and IEEE 802.1x authentication.
Technical specifications include supported modulation schemes (OFDM, BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK), power consumption ranging from 24 mA to 565 mA depending on mode, physical dimensions of 118 mm × 54 mm × 6 mm, operating temperature from –20 °C to 70 °C, and compliance with FCC, CE and other regulatory standards. This manual is written in Chinese.
Covers: Product Overview · Data Rates · Supported Standards · Frequency Bands · Security Features · Power Consumption
Latest AT-WR54BG manuals
AT-WR54BG 802.11g Turbo Mode 108Mbps AT-WR54BG high-speed 108Mbps Wireless Turbo mode network card Manual
Datasheet 3 pages · 45 KB · ZHThe AT‑WR54BG wireless card datasheet details its 108 Mbps Turbo mode, supported standards, frequency ranges, power consumption and dimensions.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in AT-WR54BG manuals
What is the maximum data rate of the AT‑WR54BG card?
The card supports a Turbo mode with a maximum data rate of 108 Mbps.
Which wireless standards does the AT‑WR54BG support?
It supports IEEE 802.11, 802.11b and 802.11g standards.
