Featured ADVVANTECH manuals
Advantech PCA-6010 Motherboard Manual
This manual describes the PCA-6010 LGA775 motherboard designed for industrial computer systems. It lists supported CPUs, memory configurations, I/O interfaces, power supplies, and physical dimensions.
Key sections cover CPU options, DDR2 memory up to 4 GB, GbE LAN via PCIe x1, multiple SATA and USB ports, optional DVI/VGA video outputs, and detailed connector pin‑outs for system integration. This manual is written in Chinese.
Covers: CPU Options · Memory Configuration · I/O Interfaces · Power Supply · Physical Dimensions · Expansion Slots
Advantech HMI Solutions Product Overview
Advantech offers a range of industrial HMI products, including Touch Panel Computers (TPC), Flat Panel Monitors (FPM), Industrial Panel PCs (IPPC) and all‑in‑one workstations (AWS). The solutions feature fanless designs, rugged enclosures, and support for Windows CE, Windows XP Embedded and other operating systems, targeting automation, control and monitoring applications.
The TPC series provides display sizes from 5.7" to 15" with AMD or Intel CPUs, NEMA4/IP65 front‑panel protection and a 0 °C‑50 °C operating temperature range. FPM displays deliver double the brightness of commercial panels, while IPPC units combine stainless‑steel and aluminum housings with high‑performance Pentium processors. AWS workstations offer up to 14 expansion slots and are built for 24‑hour continuous operation. This manual is written in Chinese.
Covers: Open HMI Solutions · Touch Panel Computer (TPC) · Flat Panel Monitor (FPM) · Industrial Panel PC (IPPC) · All‑in‑one Workstation (AWS) · NEMA4/IP65 Protection
Latest ADVVANTECH manuals
ADVANTECH TPC-1270H Manual
This document describes the specifications and features of Touch Panel Computers 6-6 TPC-1270H, including BIOS, dimensions, cooling system, OS support, power consumption, and hardware configuration.
Advantech PCA-6010 Motherboard Manual
User Manual 2 pages · 1013 KB · ZHThe Advantech PCA-6010 motherboard manual provides specifications, connector details, power requirements, and installation information for the LGA775 based…
Advantech HMI Solutions Product Overview
Product Leaflet 32 pages · 2.3 MB · ZHAdvantech’s HMI Solutions overview presents its TPC, FPM, IPPC, and AWS product families with features, specifications, and application options.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ADVVANTECH manuals
What is the maximum memory capacity of the PCA-6010?
The motherboard can accommodate up to 4 GB of DDR2 667 SDRAM.
What temperature range can the TPC series operate in?
The TPC series is rated for operation from 0 °C up to 50 °C.
What protection rating do the TPC front panels have?
The front panels meet NEMA4 / IP65 protection standards.
