Featured ACE manuals

DJI Ace One User Manual
The DJI Ace One is an autonomous navigation system for small remote‑controlled helicopters, offering GPS‑based flight modes, lock‑tail gyro, and self‑landing capabilities. It integrates a main controller, IMU, GPS/compass module, and optional internal combustion or electric motor.
This manual covers product overview, box contents, initial installation and wiring, parameter‑tuning software usage, flight‑parameter configuration, system maintenance, firmware upgrades, LED indicator meanings, and detailed specifications. This manual is written in Chinese.
Covers: Product Overview · Box Contents · Initial Installation and Connections · Wiring Diagram · Parameter Tuning Software · Flight Parameter Settings

Thunder Tiger SkyMaster TS4 2.4 GHz Digital Proportional 4-Channel Radio Control System User Manual
This manual covers the SkyMaster TS4 transmitter and its compatible receivers, describing system contents, features, and detailed specifications. It explains how to install batteries, configure the transmitter controls, and connect the receiver to a model.
Safety information, FCC compliance statements, and troubleshooting guidance are included, along with step‑by‑step procedures for binding the transmitter and receiver, performing a range‑check, and setting the failsafe function.
Covers: System Contents · Features · Specifications · Transmitter Controls · Battery Installation · Receiver Installation
Latest ACE manuals
ACE ACE24C512 EEPROM
The ACE24C512 provides wide voltage of 524,288 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 65,536 words of 8 bits each. The device
ACE ACE24C04 ACE24C08A EEPROM
The ACE24C04/08A provides low operation voltage of 4096/8192 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 512/1024 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operations are essential.
ACE ACE24C16A EEPROM
The ACE24C16A provides low operation voltage of 16384 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 2048 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operations are essential.
ACE ACE25C200 Flash Memory
The ACE25C200 is a 2M-bit (256K-byte) Serial Flash memory, with advanced write protection mechanisms. The ACE25C200 supports the standard Serial Peripheral Interface (SPI), and a high performance Dual output as well as Dual I/O. The ACE25C200 can be programmed 1 to 256 bytes at a time, using the Page Program instruction. It is designed to allow either single Sector/Block at a time or full chip erase operation. The ACE25C200 can be configured to protect part of the memory as the software protect
ACE ACE24C02C EEPROM
The ACE24C02C provides low operation voltage of 2048 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 256 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operations are essential.
ACE ACE24C32 ACE24C64 EEPROM
The ACE24C32/64 provides 32,768/65,536 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 4096/8192 words of 8 bits each. The device
ACE ACE25C100 Flash Memory
The ACE25C100 is a 1M-BIT (128K-byte) Serial Flash memory, with advanced write protection mechanisms. The ACE25C100 supports the standard Serial Peripheral Interface (SPI), and a high performance Dual output as well as Dual I/O. The ACE25C100 can be programmed 1 to 256 bytes at a time, using the Page Program instruction. It is designed to allow either single Sector/Block at a time or full chip erase operation. The ACE25C100 can be configured to protect part of the memory as the software protect
ACE ACE25C160G Flash
The ACE25C160G (16M-bit) Serial flash supports the standard Serial Peripheral Interface (SPI), and supports the Dual/Quad SPI: Serial Clock, Chip Select, Serial Data I/O0 (SI),I/O1 (SO), I/O2 (WP#), and I/O3 (HOLD#). The Dual I/O data is transferred with speed of 240Mbits/s and the Quad I/O & Quad output data is transferred with speed of 480Mbits/s.
ACE ACE24C128 ACE24C256 EEPROM
The ACE24C128/256 provides 131,072/262,144 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 16,384/32,768 words of 8 bits each. The device
ACE ACE24C1024 EEPROM
The ACE24C1024 provides wide voltage of 1,048,576 bits of serial electrically erasable and programmable read-only memory (EEPROM) organized as 131,072 words of 8 bits each. The device can be connected in series to achieve the characteristics of the four devices to share a two-wire system addressable bus. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operations are essential.
ACE RC T6AC/T6 DIGITAL BALANCE CHARGER Manual
ACE RC 8127/DS1015 8128/DS1313 SUPER TORQUE DIGITAL SERVO Manual
ACE RC 8126/DS1213 SUPER TORQUE DIGITAL SERVO Manual
ACE RC GT5 3-axis Flybarless System Manual
The GT-5 is a high performance electric stabilizing 3-axis gyro, which was designed for flying helicopters flybarless.
ACE RC TG-6000 HEADING LOCK GYRO Manual
TG-6000 is designed for mini electric R/C helicopters. Small-sized and light-weighted make it ideal and convenient for installation on your mini electric R/C helicopter. Both heading lock mode and normal mode are adopted. Also you can use a digital servo for more precise tail control.
- 1
- 2
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ACE manuals
What do the LED indicator colors mean?
Red indicates the Ace One is disconnected from the PC, green shows a successful connection, and blue signals active data communication between the Ace One and the PC.
From: DJI Ace One User Manual
How can I perform a range‑check before flying?
Activate the range‑check by pressing and holding the Binding SW button while the transmitter is on; the signal strength is reduced and a short “Bi‑Bi‑Bi” tone sounds. Move the sticks to verify servo response, then release the button to restore full power.
From: Thunder Tiger SkyMaster TS4 2.4 GHz Digital Proportional 4-Channel Radio Control System User Manual
What batteries are required for the transmitter?
The transmitter uses eight AA cells, either alkaline or rechargeable (Ni‑Cd/Ni‑MH). Install them in the battery holder with correct polarity; a 9.6 V rechargeable pack can also be used and charged via the external charging jack.
From: Thunder Tiger SkyMaster TS4 2.4 GHz Digital Proportional 4-Channel Radio Control System User Manual
