Key facts
- Manuals
- 4
- Languages
- EN · ZH
- Last added
- 2012-03-28
Featured Xenyx manuals
Behringer XENYX 1622FX/1832FX/2222FX/2442FX User Manual
This manual covers the basic concepts, signal flow, and control sections of the XENYX series mixers, including Mic Pre‑amp, Line inputs, Inserts, Trim, Low‑Cut, Balance, Mute, Solo, and various Aux Send/Return configurations. Detailed diagrams and tables illustrate how to connect microphones, instruments, and external processors.
The document also lists technical specifications such as power requirements, dimensions, frequency response, and audio performance for each model (1622FX, 1832FX, 2222FX, 2442FX). Users can reference the specifications to ensure proper installation and optimal audio quality.
Covers: Mic Pre‑amp · Line Input · Insert and Send · Trim and Low‑Cut · Balance, Mute, Solo · Aux Send / Aux Return
Behringer XENYX XL1600/XL2400/XL3200 Live Mixer User Manual
This manual introduces the XENYX XL1600/XL2400/XL3200 series, covering safety precautions, warranty terms, and basic setup instructions. It emphasizes that only qualified personnel should perform installation and repair, and warns against exposure to water or opening the chassis.
The document details the mixer’s connections—including power, network, mono and stereo inputs, main outputs, and auxiliary sends—as well as the functional layout of controls and the technical data such as power consumption, input impedance, gain range, and EQ parameters. This manual is written in Chinese.
Covers: Safety Information · Legal Notice · Warranty Terms · Getting Started · Quick Start · Installation
Behringer XENYX 1222FX User Manual
This manual introduces the XENYX 1222FX mixing console, describing its high‑quality microphone pre‑amps, balanced line inputs, built‑in effects processor and optional phantom power. It includes safety warnings, proper handling, and warranty information.
The guide covers installation into a rack, power and cable connections, detailed descriptions of each channel’s controls, the digital effects and XPQ surround functions, and a full set of technical data such as power requirements, dimensions and input specifications. This manual is written in Chinese.
Covers: Safety Instructions · Operation Controls and Interfaces · Digital Effects Processor and XPQ Surround Function · Installation · Technical Data · Warranty Service
Latest Xenyx manuals
XENYX 1202/1002/802/502 Manual
This document is the user manual for the BEHRINGER XENYX 1202/1002/802/502 series mixers, which provides information about the features, operation elements and interfaces, installation methods, and technical specifications of the mixers.
Behringer XENYX 1622FX/1832FX/2222FX/2442FX User Manual
User Manual 14 pages · 3.5 MB · ENThe Behringer XENYX 1622FX/1832FX/2222FX/2442FX user manual provides setup, routing, and operation instructions for these mixers.
Behringer XENYX XL1600/XL2400/XL3200 Live Mixer User Manual
User Manual 21 pages · 6.5 MB · ZHThe Behringer XENYX XL1600/XL2400/XL3200 user manual provides safety information, installation steps, wiring diagrams, operation guidance, and technical…
Behringer XENYX 1222FX User Manual
User Manual 10 pages · 2.4 MB · ZHThe Behringer XENYX 1222FX User Manual provides operating instructions, safety guidelines, installation steps, and technical specifications for the mixing…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Xenyx manuals
What voltage and frequency does the XENYX series require?
The mixers operate from 100 V to 240 V at 50 Hz to 60 Hz.
From: Behringer XENYX 1622FX/1832FX/2222FX/2442FX User Manual
How much power does the 1622FX model consume?
The 1622FX consumes 37 W.
From: Behringer XENYX 1622FX/1832FX/2222FX/2442FX User Manual
What safety precautions are required when installing the XENYX XL1600/XL2400/XL3200?
Do not open the chassis, keep the unit away from water, ensure proper grounding, and have all installation or adjustments performed by qualified professionals.
From: Behringer XENYX XL1600/XL2400/XL3200 Live Mixer User Manual
How should the power supply be connected to the mixer?
Connect the supplied power cable to the IEC power socket, make sure the unit is grounded, and turn the POWER switch to OFF before plugging or unplugging.
From: Behringer XENYX XL1600/XL2400/XL3200 Live Mixer User Manual
How can I connect a microphone that requires phantom power?
Connect the microphone to a balanced XLR mic input, then enable phantom power with the PHANTOM switch; do not use an unbalanced XLR connection.
