Key facts
- Manuals
- 3
- Languages
- EN · ZH
- Last added
- 2012-04-01
Featured ProSoft manuals
ProSoft MVI56-PDPMV1 PROFIBUS DPV1 Master User Manual
The MVI56-PDPMV1 is a PROFIBUS DPV1 Master module designed for Rockwell Automation ControlLogix processors. It provides a communication interface between the ControlLogix backplane and PROFIBUS devices, supporting both legacy and FLEX mailbox modes and a range of diagnostic features.
The manual covers safety and installation instructions for hazardous locations, wiring requirements, module configuration with ProSoft Configuration Builder, mailbox messaging, diagnostics, and warranty information. It also includes detailed hardware specifications, functional descriptions, and sample ladder logic programs.
Covers: Important Installation Instructions · Warnings · Battery Life Advisory · Markings · Configuring the MVI56-PDPMV1 Module · Mailbox Messaging
ProSoft MVI56-MCM ControlLogix Modbus Communication Module User Manual
This manual provides detailed information for the MVI56-MCM Modbus communication module that connects Allen‑Bradley ControlLogix processors to Modbus‑compatible devices. It covers safety precautions, module concepts, and the overall data flow between the processor, the module, and the Modbus network.
Key sections include module installation, configuration of ports and parameters, sample ladder‑logic programs, diagnostics, cable connections, and full product specifications. Appendices list database definitions, status data, command control and hardware details. This manual is written in Chinese.
Covers: Introduction · Understanding Structure · Modifying Module Settings · Sample Ladder Logic Programs · Diagnostics and Error Correction · Cable Connections
Latest ProSoft manuals
ProSoft MVI69-DFCM user manual
This manual provides information about the MVI69-DFCM CompactLogix Platform DF1 Interface Module. It includes: Overview, Connections, Configuration, and Installation.
ProSoft MVI56-PDPMV1 PROFIBUS DPV1 Master User Manual
User Manual 255 pages · 5.7 MB · ENThe ProSoft MVI56-PDPMV1 User Manual provides installation, wiring, configuration and troubleshooting guidance for the PROFIBUS DPV1 Master module.
ProSoft MVI56-MCM ControlLogix Modbus Communication Module User Manual
User Manual 99 pages · 1.3 MB · ZHThe ProSoft MVI56-MCM User Manual explains setup, configuration, and operation of the Modbus communication module for Allen‑Bradley ControlLogix systems.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ProSoft manuals
What explosion‑hazard warnings apply to the MVI56-PDPMV1?
The module must be installed according to Class I, Division 2 wiring methods, and power must be turned off before replacing or wiring modules in hazardous locations.
What are the electrical ratings of the MVI56-PDPMV1 module?
The backplane current load is 800 mA at 5 VDC and 3 mA at 24 VDC.
What is the current load rating of the MVI56-MCM module?
The module draws up to 800 mA at 5 V from the backplane.
From: ProSoft MVI56-MCM ControlLogix Modbus Communication Module User Manual
What temperature range can the module operate in?
It operates from 0 °C to 60 °C (32 °F to 140 °F).
From: ProSoft MVI56-MCM ControlLogix Modbus Communication Module User Manual
