Featured Wuhan吉阳光电 manuals
Glinker GY7508 RS232-SPI Module User Manual
The GY7508 is a single‑channel RS232 (UART) to SPI bus converter that provides a standard SPI master interface and optional slave mode. It operates from a +5 V supply, outputs 3.3 V TTL signals and supports SPI clock rates up to 12 MHz. The module includes pins for baud‑rate selection, power, ground and the four SPI signals (SCK, MISO, MOSI, CS0).
The manual details the hardware layout, pin definitions, electrical characteristics, baud‑rate configuration, and a full set of serial commands for configuring SPI mode, channel, clock frequency and performing Easy‑SPI read/write operations. Example code for common SPI devices such as EEPROMs and DACs is provided, along with timing diagrams and application schematics. This manual is written in Chinese.
Covers: Product Introduction · Physical Dimensions and Pin Description · Electrical Characteristics · Serial Baud‑Rate Settings · Software Command Set and Examples · SPI Interface and Timing
Geeyang technology GY7601/GY7602/GY7604/GY7608 RS232-I2C Adapter Manual
The GY760x series provides RS232‑to‑I2C conversion with 1‑8 independent I2C channels, supporting standard I2C master mode and SMBus compatibility. It is powered from a +5 V supply and offers both Easy I2C and Timing I2C operation modes for simple or precise bus control.
The document includes electrical characteristics, connector definitions, baud‑rate configuration, a full list of serial commands, examples of using the VCI_GYI2C library for custom software development, troubleshooting tips, and application diagrams for connecting PCs or embedded controllers. This manual is written in Chinese.
Covers: Performance and Technical Specifications · Typical Applications · Communication Protocol Conversion · Physical Appearance and Interface Description · Electrical Characteristics · Serial Baud‑Rate Settings
Geeyang GY7501 USB-I2C Adapter User Manual
This manual describes the GY7501 USB‑I2C Adapter produced by Geeyang (武汉吉阳光电科技有限公司). It covers product specifications, physical dimensions, pin assignments, and typical applications such as I2C bus testing and EEPROM access.
The document also explains how to install the provided driver and DCTools software, outlines the available API functions for C/C++ development, and lists technical support contacts and accessories included with the adapter. This manual is written in Chinese.
Covers: Product Introduction · Performance and Technical Specifications · Typical Applications · Physical Appearance and Interface Description · ECSlaveTools Software · Driver Installation
Glinker GY7632 RS232‑SPI Adapter User Manual
The GY7632 RS232‑SPI Adapter provides a conversion between a standard RS232 DB9 serial port and a dual‑channel SPI bus. It supplies 3.3 V TTL output, accepts 5 V TTL input, and supports up to 12 MHz SPI clock rates. The device is powered from a +5 V supply and measures 70 × 45 mm.
The manual describes the physical connectors, electrical characteristics, default serial baud rate (115200 bps), how to change baud settings, software command set for SPI read/write operations, timing diagrams, and example applications such as EEPROM programming. Troubleshooting tips address common connection and command issues. This manual is written in Chinese.
Covers: Product Overview · Physical Dimensions and Connectors · Electrical Characteristics · Serial Port Baud Rate Settings · Software Commands and Examples · SPI Interface and Timing
Latest Wuhan吉阳光电 manuals
Glinker GY7508 RS232-SPI Module User Manual
User Manual 15 pages · 188 KB · ZHThe GY7508 RS232‑SPI module manual explains features, electrical specs, command set and wiring for the single‑channel SPI converter.
Geeyang technology GY7601/GY7602/GY7604/GY7608 RS232-I2C Adapter Manual
User Manual 13 pages · 191 KB · ZHThe manual details performance, electrical specs, pinouts, serial command set, software library and application examples for the GY760x RS232‑I2C adapter.
Geeyang technology GY8507 USB-CAN adapter Manual
Geeyang technology GY7502 USB-SPI Adapter products Manual
Geeyang GY7501 USB-I2C Adapter User Manual
User Manual 13 pages · 315 KB · ZHThe Geeyang GY7501 USB‑I2C Adapter User Manual provides specifications, connection details, software installation, and programming guidance.
Geeyang technology GY7501A/GY7512 USB-I2C Adapter products Manual
Glinker GY7632 RS232‑SPI Adapter User Manual
User Manual 14 pages · 161 KB · ZHUser manual for the Glinker GY7632 RS232‑SPI adapter, covering specifications, wiring, commands and troubleshooting.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Wuhan吉阳光电 manuals
What is the default serial baud rate if the COMSET pins are left floating?
The default baud rate is 115200 bps when the COMSET pins are not connected.
How many SPI channels does the GY7508 provide?
The GY7508 provides a single SPI channel (CS0).
How do I install the driver for the GY7501 adapter?
Connect the adapter to a PC USB port, then run the provided driver installer and select the driver folder as prompted.
What software is supplied with the GY7501 adapter?
The package includes the DCTools I2C utility, a DLL library with API functions, and Visual C++ example code.
What is the default serial baud rate of the GY7632 adapter?
The adapter ships with a default serial baud rate of 115200 bps.
How can the serial baud rate be changed?
Baud rate is selected by the COMSET0 and COMSET1 pins: shorting a pin to GND sets a ‘0’, leaving it floating sets a ‘1’. The combination determines the baud rate.
