Featured BPsemi manuals
BPsemi BP3236C LED Driver Chip Datasheet
The BP3236C LED driver chip from BPsemi supports TRIAC dimming and operates in critical continuous‑current mode, suitable for Buck, Buck‑Boost and Fly‑back LED power supplies. It integrates a 500 V power MOSFET and uses a patented JFET‑powered architecture that requires minimal external components for excellent constant‑current performance.
The device includes extensive protection functions such as LED open‑circuit, short‑circuit, over‑voltage, undervoltage, and over‑temperature regulation. It is offered in an SOP‑8 package and is intended for applications like LED bulbs, candle‑type LEDs, and other general lighting solutions. This manual is written in Chinese.
Covers: Features · Pin Configuration · Absolute Maximum Ratings · Electrical Parameters · Internal Block Diagram · Application Information
BPsemi BP2833D Non-isolated Buck Offline LED Driver Datasheet
The BP2833D is a non‑isolated buck constant‑current LED driver designed for 85 Vac‑265 Vac offline lighting. It integrates a 500 V power MOSFET, operates in critical conduction mode, and requires very few external components, reducing system size and cost. The device provides ±5 % LED current accuracy and a range of protection functions including LED open/short protection, CS‑resistor short protection, VCC undervoltage protection and thermal regulation.
Typical applications include LED tubes, ceiling lights and bulbs. Key specifications are a DIP‑8 package, operating temperature from –40 °C to 105 °C, output LED currents of 320 mA (72 V) and 360 mA (36 V), and a 500 V MOSFET rating. Recommended PCB layout guidelines emphasize short ground paths, close bypass capacitors and proper placement of the ROVP resistor for reliable operation.
Covers: Description · Features · Applications · Ordering Information · Pin Configuration · Absolute Maximum Ratings
Latest BPsemi manuals
BPsemi BP3236C LED Driver Chip Datasheet
Datasheet 9 pages · 610 KB · ZHThe BP3236C is a high‑efficiency, TRIAC‑dimmable LED driver chip with integrated 500 V power switch and multiple protection features.
BPsemi BP2833D Non-isolated Buck Offline LED Driver Datasheet
Datasheet 8 pages · 407 KB · ENThe BP2833D is a high‑precision, non‑isolated buck LED driver with an internal 500 V MOSFET, low operating current and extensive protection features.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in BPsemi manuals
What protection functions does the BP3236C provide?
It includes LED open‑circuit, LED short‑circuit, over‑voltage, undervoltage, CS‑resistor short‑circuit, and over‑temperature protection.
What is the recommended operating temperature range?
The chip is rated for a junction temperature from –40 °C up to 150 °C.
What protection functions does the BP2833D provide?
It includes LED open circuit protection, LED short circuit protection, CS‑resistor short protection, VCC undervoltage protection and thermal regulation.
From: BPsemi BP2833D Non-isolated Buck Offline LED Driver Datasheet
How many external components are required for the BP2833D?
Only a few external components are needed because the driver integrates a 500 V MOSFET and does not require an auxiliary winding.
From: BPsemi BP2833D Non-isolated Buck Offline LED Driver Datasheet
