Beacon Global Technology Manuals

Key facts

Manuals: 3
Languages: ZH
Last added: 2026-09-29

Featured Beacon Global Technology manuals

Beacon Global Technology BT-MT-MT-S Quick Start Guide

Quick Start Guide 21 pages · 1.5 MB · ZH

The BT-MT-MT-S module supports up to two simultaneous Modbus TCP servers and five Modbus TCP clients, allowing flexible networking in the same or different IP subnets. It provides 16‑bit WORD registers whose quantity varies by model, and offers web‑based configuration via standard browsers.

The guide explains how to set the module's IP address, log in to the web interface, configure server and client settings, and use ModScan32 or similar tools for testing. Example applications demonstrate communication between multiple master stations and between a slave and multiple masters. This manual is written in Chinese.

Covers: BT-MT-MT Introduction · Beacon Module Protocol Overview · Initial Module Configuration · Configuring Modbus TCP Server · Configuring Modbus TCP Client · Example 1: Communication Between Two Modbus TCP Masters

Beacon Global Technology BT-MT-DF-S Quick Start Guide

Quick Start Guide 20 pages · 1.4 MB · ZH

The BT-MT-DF-S is a Modbus TCP‑DF1 communication module that supports data exchange between Modbus TCP Ethernet networks and DF1 serial networks. It provides up to 8000 bytes of data exchange area and can act as both Modbus TCP server/client and DF1 master.

The guide explains how to access the web‑based configuration interface, set the IP address, change passwords, configure Modbus TCP and DF1 settings, and includes two example scenarios for data exchange with LOGIX500 PLCs. This manual is written in Chinese.

Covers: BT-MT-DF-S Introduction · Module Initial Configuration · Configure as Modbus TCP Server · Configure as Modbus TCP Client · Configure as DF1 Master · Example 1: Modbus TCP ↔ LOGIX500 Data Exchange

Beacon Global Technology BT-EN-DF-S Quick Start Guide

Quick Start Guide 24 pages · 2.2 MB · ZH

This guide introduces the BT-EN-DF-S series module, an EtherNet/IP‑DF1 communication device that can exchange up to 8000 bytes of data between Ethernet and DF1 serial networks. It describes the module’s hardware interfaces, default settings, and supported Rockwell PLC families.

The manual walks the user through initial configuration via a web browser, setting the IP address, logging in, and configuring the module as an EtherNet/IP server, client, or DF1 master. Example projects show data exchange between Logix5000 and Logix500 PLCs, and contact information is provided for technical support. This manual is written in Chinese.

Covers: Introduction · Initial Module Configuration · Configure as EtherNet/IP Server · Configure as EtherNet/IP Client · Configure as DF1 Master · Example 1: Logix5000 ↔ Logix500 Data Exchange

Latest Beacon Global Technology manuals

Beacon Global Technology BT-MT-MT-S Quick Start Guide
Quick Start Guide 21 pages · 1.5 MB · ZH
Quick start guide for the Beacon Global Technology BT-MT-MT-S Modbus TCP communication module, covering configuration, server/client setup and examples.
Beacon Global Technology BT-MT-DF-S Quick Start Guide
Quick Start Guide 20 pages · 1.4 MB · ZH
Quick start guide for the BT-MT-DF-S Modbus TCP‑DF1 communication module, covering initial setup, configuration and example data exchanges.
Beacon Global Technology BT-EN-DF-S Quick Start Guide
Quick Start Guide 24 pages · 2.2 MB · ZH
Quick start guide for the Beacon Global Technology BT-EN-DF-S EtherNet/IP‑DF1 communication module.
