Featured FSBREC manuals
FSBREC BR8205(BRCS8205MF) N-Channel Double MOSFET Data Sheet
The BR8205 (BRCS8205MF) is an N‑channel double MOSFET supplied in a SOT23‑6 plastic package. It uses advanced trench technology to achieve low on‑resistance and low gate charge, making it suitable for battery‑protection and other switching applications.
The document provides detailed electrical characteristics, absolute maximum ratings, marking instructions, package dimensions, reflow soldering temperature profile and packaging information for the device.
Covers: Features · Applications · Electrical Characteristics · Absolute Maximum Ratings · Package Dimensions · Marking Instructions
FSBREC MB1F-05 to MB10F-05 Surface Mount Glass Passivated Bridge Rectifier Datasheet
The MB1F‑05 to MB10F‑05 series are 0.5 A surface‑mount bridge rectifiers with a glass‑passivated MBF thin package, designed for general‑purpose use and halogen‑free applications. They support reverse voltages from 100 V up to 1000 V and feature high surge‑current capability.
The datasheet includes detailed electrical specifications, pin‑out information, package drawings, marking codes, and a recommended lead‑free reflow soldering temperature profile. Packaging options and reel dimensions are also listed.
Covers: Features · Applications · Equivalent Circuit · Pinning · Electrical Characteristics · Package Dimensions
Latest FSBREC manuals
FSBREC BR8205(BRCS8205MF) N-Channel Double MOSFET Data Sheet
Datasheet 6 pages · 1.3 MB · ENData sheet for the FSBREC BR8205 (BRCS8205MF) N‑channel double MOSFET, covering electrical specs, package dimensions and thermal profiles.
FSBREC MB1F-05 to MB10F-05 Surface Mount Glass Passivated Bridge Rectifier Datasheet
Datasheet 7 pages · 677 KB · ENThe FSBREC MB1F-05 to MB10F-05 datasheet provides electrical characteristics, package dimensions, marking instructions, and reflow soldering profile for a…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in FSBREC manuals
What is the maximum drain‑source voltage of the BR8205?
The device can withstand up to 20 V drain‑source voltage.
From: FSBREC BR8205(BRCS8205MF) N-Channel Double MOSFET Data Sheet
Which package type does the BR8205 use?
It is supplied in a SOT23‑6 plastic package.
From: FSBREC BR8205(BRCS8205MF) N-Channel Double MOSFET Data Sheet
What is the maximum reverse voltage rating?
The device can withstand reverse voltages from 100 V up to 1000 V.
From: FSBREC MB1F-05 to MB10F-05 Surface Mount Glass Passivated Bridge Rectifier Datasheet
What is the recommended peak temperature for lead‑free reflow soldering?
The peak temperature should be 245 °C ± 5 °C for a duration of 5 ± 0.5 seconds.
From: FSBREC MB1F-05 to MB10F-05 Surface Mount Glass Passivated Bridge Rectifier Datasheet
