Featured HMI Tech manuals
HMITECH TPC156TA-Li Datasheet
The TPC156TA-Li is a 15.6" smart industrial device featuring a high‑resolution TFT LCD (1920×1080) and support for Intel i5/i7 processors. It can be equipped with up to 16 GB RAM and up to 512 GB of solid‑state storage.
The unit offers a rich set of I/O options, including RS‑232, RS‑485, USB 3.0, Gigabit LAN and audio ports, and is built to operate in harsh environments with temperature ranges from –20 °C to 70 °C and humidity up to 96 %.
The datasheet also outlines the physical dimensions (427 × 276 × 55 mm), environmental storage limits, and the three‑year warranty provided by HMITECH.
Covers: Display Specifications · Processor and Memory · Storage Options · Interface Overview · Environmental Conditions · Physical Dimensions
HMI Tech TPC101TA-Le Industrial Touch Panel Computer User Manual
The TPC101TA-Le is a 10.1" industrial touch panel computer featuring a low‑power dual‑core CPU, up to 8 GB RAM, and a 1280 × 800 TFT LCD with 350 cd/m² brightness. It supports Windows 7, Windows 10, Linux and offers 10‑point touch, multiple USB, LAN and serial interfaces, and a rugged metal enclosure.
The manual lists the hardware specifications, connector pin‑outs, environmental limits, warranty terms and contact information for HMI Tech. It also includes power requirements, dimensions, and storage options, helping users install, operate, and service the device.
Covers: Product Specifications · Panel Interface · Serial Port Details · Warranty Information · Contact Information
Latest HMI Tech manuals
HMITECH TPC156TA-Li Datasheet
Datasheet 8 pages · 393 KB · ENThe HMITECH TPC156TA-Li datasheet provides technical specifications, interface details, dimensions, environmental limits, and warranty information for the…
HMI Tech TPC101TA-Le Industrial Touch Panel Computer User Manual
User Manual 8 pages · 468 KB · ENThe HMI Tech TPC101TA-Le user manual provides specifications, port details, operating temperature ranges, and warranty information for the 10.1" industrial…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in HMI Tech manuals
What are the display specifications of the TPC156TA-Li?
It has a 15.6" TFT LCD with a resolution of 1920×1080 and a brightness of 350 cd/m².
Which interfaces are provided on the TPC156TA-Li?
The device includes 2 RS‑232 ports, 1 RS‑485/232 (9‑pin) port, 3 RS‑485 ports, 4 USB 3.0 ports, 2 Gigabit LAN ports, and 1 audio port.
What operating temperature range does the TPC101TA-Le support?
It operates from 0 °C up to 50 °C.
From: HMI Tech TPC101TA-Le Industrial Touch Panel Computer User Manual
How many USB ports are available on the TPC101TA-Le?
The device provides three USB 2.0 ports and one USB 3.0 port.
From: HMI Tech TPC101TA-Le Industrial Touch Panel Computer User Manual
