Featured HeyLEMC manuals
HeyLeMC FP-SURGE100M2 Surge Three-Phase Coupled/Decoupled Network Product Leaflet
The FP‑SURGE100M2 provides automatic coupling path selection for IEC or ANSI standards, offering high‑voltage safety interlock connections and synchronized pulse paths. It is designed for testing three‑phase AC and DC power ports according to IEC, EN and ANSI requirements.
Key features include combined waveforms (1.2/50 µs‑8/20 µs), 100 kHz ringing wave, 8 kV pulse voltage, 690 V line‑to‑line voltage, and 100 A per‑phase current capability. The unit weighs 220 kg and measures 60 × 100 × 190 cm. This manual is written in Chinese.
Covers: Overview · Features · Advantages · Applications · Technical Specifications · Supply Range
HeyLEMC FP-COMB 32 Combination Automatic Three‑Phase Coupling/Decoupling Network Product Leaflet
The FP-COMB 32 is an automatic three‑phase coupling/decoupling network controlled by the axos5/axos8 test system. It can automatically change coupling paths, phase angles and source impedance based on user‑set parameters to satisfy IEC/EN 61000‑4‑4, ‑5, ‑12 and ANSI C62.41/ C62.45 requirements for surge, ringing and pulse‑group testing.
Key features include support for surge combination waves, ringing waves up to 100 kHz, EFT/burst pulses, 7 kV surge voltage, 5 kV pulse voltage, 480 V line voltage, 32 A per phase current, and synchronized phase paths. The device offers remote control via axos5/axos8, LED status display, and automatic IEC/ANSI synchronization. This manual is written in Chinese.
Covers: Overview · Features · Advantages · Applications · Technical Specifications · Supply Scope
Latest HeyLEMC manuals
HeyLeMC FP-SURGE100M2 Surge Three-Phase Coupled/Decoupled Network Product Leaflet
Product Leaflet 3 pages · 357 KB · ZHThe HeyLeMC FP-SURGE100M2 is a surge test device for three‑phase AC/DC power ports, supporting IEC, EN and ANSI standards with up to 100 A per phase.
HeyLEMC FP-COMB 32 Combination Automatic Three‑Phase Coupling/Decoupling Network Product Leaflet
Product Leaflet 3 pages · 213 KB · ZHThe HeyLEMC FP-COMB 32 is a three‑phase coupling/decoupling network that meets IEC/EN 61000‑4‑4, ‑5 and ‑12 surge test standards.
Questions answered in HeyLEMC manuals
What is the maximum current per phase?
The device can handle up to 100 A per phase for both AC and DC loads.
From: HeyLeMC FP-SURGE100M2 Surge Three-Phase Coupled/Decoupled Network Product Leaflet
Can the device automatically select the correct coupling option for IEC or ANSI?
Yes, the user can select IEC or ANSI mode and the unit automatically chooses the appropriate coupling option.
From: HeyLeMC FP-SURGE100M2 Surge Three-Phase Coupled/Decoupled Network Product Leaflet
What is the maximum current per phase for the FP-COMB 32?
The device can handle up to 32 A per phase.
From: HeyLEMC FP-COMB 32 Combination Automatic Three‑Phase Coupling/Decoupling Network Product Leaflet
What input voltage range does the FP-COMB 32 support?
It supports an input voltage from 10 V to 480 V.
From: HeyLEMC FP-COMB 32 Combination Automatic Three‑Phase Coupling/Decoupling Network Product Leaflet
