Featured Zhongweixing manuals
Zhongweixing ADT-8989G1 8-Axis Motion Control Card User Manual
This document introduces the ADT-8989G1 8‑axis motion control card, a PCI‑bus based high‑performance controller designed for applications such as engraving, cutting, milling, punching and drilling. It details the hardware architecture, supported software environments, and typical industry uses.
The manual includes a quick‑start guide, hardware connection diagrams, step‑by‑step installation procedures, basic debugging instructions, and an appendix with common troubleshooting topics and safety precautions. This manual is written in Chinese.
Covers: Overview · Quick Start · Hardware Connection · Basic Debugging · Appendix
Zhongweixing ADT-8933 Triaxial Motion & Laser Control Card Manual
The ADT-8933 is a high‑performance PCI‑based three‑axis servo/stepper and laser control card that can manage up to 48 motors and supports up to 16 cards in one system. It offers 2 MHz pulse output, 0.1 % frequency error, and 32‑bit position counters.
The document covers product overview, hardware installation, signal connections, software drivers for Windows/DOS, function description, parameter settings, example programs in VB and VC++, and a troubleshooting guide. This manual is written in Chinese.
Covers: Overview · Hardware Installation · Signal Connections · Software Installation · Function Description · Basic Parameter Settings
Latest Zhongweixing manuals
Zhongweixing ADT-8989G1 8-Axis Motion Control Card User Manual
User Manual 54 pages · 3.2 MB · ZHThe manual provides product overview, installation, hardware connection, basic debugging and troubleshooting for the ADT-8989G1 8‑axis motion control card.
Zhongweixing ADT-8933 Triaxial Motion & Laser Control Card Manual
User Manual 76 pages · 636 KB · ZHThe manual provides overview, hardware installation, software setup, and troubleshooting for the ADT-8933 three‑axis motion and laser control card.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Zhongweixing manuals
Why can't the control card be detected during driver installation?
The manual lists this as a common issue; check the connection, ensure the PCI slot is functional, and verify that the driver version matches the card.
From: Zhongweixing ADT-8989G1 8-Axis Motion Control Card User Manual
What should I do if the control card initialization fails with error code 9?
Error code 9 indicates a WINIO initialization failure; verify that the WINIO driver is properly installed and that the system has the required permissions.
From: Zhongweixing ADT-8989G1 8-Axis Motion Control Card User Manual
What is the maximum pulse frequency of the ADT-8933?
The card can output pulses up to 2 MHz.
From: Zhongweixing ADT-8933 Triaxial Motion & Laser Control Card Manual
What is the range of the position counter?
The 32‑bit counter covers –2,147,483,648 to +2,147,483,647.
From: Zhongweixing ADT-8933 Triaxial Motion & Laser Control Card Manual
