Key facts
- Manuals
- 2
- Languages
- EN
- Last added
- 2026-09-29
Featured Thermal Tronics manuals
Thermaltronics TMT-ST10 Solder Tip Tester User Manual
This user manual provides step‑by‑step instructions for unpacking, assembling, and operating the TMT‑ST10 solder tip tester, including how to measure tip temperature, resistance and leakage. It also describes the control panel functions, data storage, and software for downloading test results.
Additional sections cover system specifications, warranty terms, calibration procedures, ordering information for accessories, and contact details for support.
Covers: Specifications · Introduction · System Features · Control Panel · Unpacking/Assembly/Operation · Software Functionality
Thermaltronics T80TZ160 Tweezers Cartridge Pair Datasheet
The T80TZ160 Tweezers Cartridge Pair is a precision tip cartridge offered by Thermaltronics. It is designed for use with the TMT-5000S‑1 and TMT-5000S‑2 tweezers, featuring a patented color‑banded tip that can idle within a narrow temperature window.
The datasheet details the operating temperature range, RoHS and lead‑free status, material composition, and tip geometry. It also notes that idle temperature can vary by ±1.1 °C depending on tip size and measurement method.
Covers: Technical Specifications · Temperature Range · RoHS Compliance · Lead‑Free Status · Compatibility · Material Composition
Latest Thermal Tronics manuals
Thermaltronics TMT-ST10 Solder Tip Tester User Manual
User Manual 13 pages · 978 KB · ENThe Thermaltronics TMT‑ST10 manual explains setup, operation, software use, calibration and warranty for the solder tip tester.
Thermaltronics T80TZ160 Tweezers Cartridge Pair Datasheet
Datasheet 1 pages · 83 KB · ENThermaltronics T80TZ160 tweezers cartridge pair datasheet provides temperature range, RoHS compliance, material composition, tip dimensions and compatible…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Thermal Tronics manuals
What is the warranty period for the TMT‑ST10 tester and its accessories?
The TMT‑ST10 solder tip tester has a 1‑year warranty, while the ground wires and mini USB cable have 30‑day warranties.
How do I switch between Celsius and Fahrenheit on the display?
Press the "RESET" button while in Temperature mode to toggle the display between °C and °F.
What is the operating temperature range of the T80TZ160 cartridge?
The T80TZ160 operates between 420 °C and 475 °C.
From: Thermaltronics T80TZ160 Tweezers Cartridge Pair Datasheet
Which tweezers models are compatible with the T80TZ160 cartridge?
It is compatible with the TMT‑5000S‑1 and TMT‑5000S‑2 models.
From: Thermaltronics T80TZ160 Tweezers Cartridge Pair Datasheet
