Featured Metz Connect manuals
Metz Connect RT045xxUBLC Data Sheet
The RT045xxUBLC is a screw‑type terminal block with a black PA66 insulating body and copper‑zinc terminals. It is designed for solderable connections and can be fitted without loss of poles.
Key specifications include a rated voltage of 250 V, rated current of 24 A, IP20 protection, operating temperature from –40 °C to 105 °C, and a tightening torque of 0.5 Nm (SEV). The block supports 2 to 24 poles and meets overvoltage category III requirements.
Covers: Product specification · Technical Data · General Data · Illustration · PCB Layout
METZ CONNECT P|Cabling Product Catalog
This catalog presents the METZ CONNECT P|Cabling range for building and industrial networking. It covers copper and fiber‑optic components such as single‑port modules, wall outlets, patch panels, IP‑protected connectors, patch and installation cables, as well as assorted cabling aids.
Each product entry includes part numbers, packing details, dimensions, weight and compliance information (e.g., ISO/IEC 11801, TIA/EIA‑568). The later sections provide test and checking devices and a comprehensive set of tools for installation and maintenance.
Covers: Single Port Modules/Plugs · Wall Outlets · Patch Panels/Distributors · IP Protected Connectors · Patch Cables · Installation Cables
Latest Metz Connect manuals
Metz Connect RT045xxUBLC Data Sheet
Datasheet 4 pages · 309 KB · ENThe Metz Connect RT045xxUBLC data sheet provides specifications, electrical ratings, dimensions and material details for the screw‑type terminal block.
METZ CONNECT P|Cabling Product Catalog
Product Leaflet 240 pages · 11.4 MB · ENThe METZ CONNECT P|Cabling Product Catalog lists single‑port modules, plugs, wall outlets, patch panels, distributors, IP‑protected connectors and cables…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Metz Connect manuals
What is the rated voltage and current of the RT045xxUBLC terminal block?
It is rated for 250 V and 24 A.
What temperature range can the RT045xxUBLC operate in?
The block can operate from –40 °C up to 105 °C.
What frequency class do the Cat.6 A modules meet?
The Cat.6 A Class E ALink modules are rated for 500 MHz.
Can the modules support Power over Ethernet?
Yes, the modules are suitable for PoE and PoE plus.
