Innovate Motorsports LC-1 Sensor Controller User Manual
The LC-1 is a stand‑alone wideband controller that measures air‑fuel ratio (AFR) or Lambda for gasoline, diesel and alternative‑fuel engines. The manual covers mounting the sensor, wiring the controller to a vehicle’s electrical system, and connecting to ECUs or data loggers.
Key sections include step‑by‑step installation, free‑air and heater calibration procedures, programming of analog outputs, and detailed troubleshooting with error‑code tables. Safety warnings emphasize the high temperature of the oxygen sensor and proper grounding practices.
Covers: Overview · Mounting and Wiring the LC‑1 · First Time Use · Calibration · Remote Display and Recording · Programming the LC‑1
Innovate Motorsports ECF-1 Gauge User Manual
The ECF-1 is a four‑in‑one gauge that measures ethanol content, fuel temperature, fuel pressure, and wideband air‑fuel ratio. It can operate stand‑alone or be integrated with other Innovate Motorsports devices via digital I/O and four configurable analog outputs.
The manual covers gauge mounting, wiring diagrams, sensor installation (wideband O₂, flex‑fuel, pressure), calibration procedures, software setup with LogWorks and LM Programmer, troubleshooting error codes, and warranty information.
Covers: Changing the ECF-1’s gauge face and/or bezel · Installation and Wiring · Gauge Mounting and Routing · Wideband Oxygen Sensor Setup · Flex Fuel Sensor Installation · Fuel Pressure Sensor Installation
Latest Innovate Motorsports manuals
Innovate Motorsports LC-1 Sensor Controller User Manual
User Manual 24 pages · 199 KB · ENInstallation, wiring, calibration and troubleshooting guide for the Innovate Motorsports LC-1 wide‑band sensor controller.
Innovate Motorsports ECF-1 Gauge User Manual
User Manual 18 pages · 292 KB · ENThe Innovate Motorsports ECF-1 gauge manual provides installation, wiring, sensor setup, and configuration instructions for the four‑in‑one ethanol, fuel…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Innovate Motorsports manuals
What fuse size should be used for the LC‑1 power connection?
The power connection must be protected by a fuse of at least 5 A.
From: Innovate Motorsports LC-1 Sensor Controller User Manual
