Featured Infineon Technologies manuals

Infineon Technologies 755>26892F Datasheet

Datasheet 13 pages · 685 KB · EN

This datasheet presents the technical specifications of the Infineon component model 755>26892F, including its electrical parameters, package type, and dimensional data. The document also contains revision information and an erratum for the TO-247 package outline.

A legal disclaimer is included, stating the limits of liability and warranty for the component, and noting that the device may be used in life‑support, automotive, aviation and aerospace applications only with Infineon’s written approval.

Covers: Legal Disclaimer · Data Sheet Erratum · Package Outline · Dimensions · Revision Information

Infineon BTS737S3 Smart High-Side Power Switch Datasheet

Datasheet 15 pages · 279 KB · EN

The BTS737S3 is a four‑channel N‑channel vertical power MOSFET with integrated charge pump, CMOS‑compatible input, and diagnostic feedback. It is designed for µC‑compatible high‑side switching of 12 V and 24 V grounded loads, including resistive, capacitive, and lamp loads, and can replace electromechanical relays, fuses, and discrete circuits.

Key specifications include an operating voltage range of 5.0 V to 40 V, on‑state resistance as low as 30 mΩ, nominal load current of 5.4 A per channel, and a current‑limit capability up to 45 A. The device incorporates multiple protection functions such as short‑circuit, overload, current‑limit, thermal shutdown, reverse‑battery, over‑voltage, loss‑of‑ground, and ESD protection, along with a proportional load‑current sense output for diagnostics.

Covers: Product Summary · General Description · Basic Functions · Protection Functions · Diagnostic Function · Pin Definitions and Functions

Infineon Technologies IPD06N03LA, IPF06N03LA, IPS06N03LA, IPU06N03LA Power-Transistor Datasheet

Datasheet 12 pages · 420 KB · EN

The OptiMOS®2 Power‑Transistor series includes four N‑channel, logic‑level devices (IPD06N03LA, IPF06N03LA, IPS06N03LA, IPU06N03LA) designed for high‑frequency DC/DC converters and other demanding applications. Key features are low gate charge·RDS(on) product, high current capability, and a wide operating temperature range.

The datasheet lists maximum ratings, electrical and thermal characteristics, dynamic behavior, and detailed package outlines. For further information, contact an Infineon Technologies office or representative as indicated on the last page.

Covers: Features · Maximum Ratings · Electrical Characteristics · Thermal Characteristics · Dynamic Characteristics · Package Outline

Latest Infineon Technologies manuals

• Infineon Technologies 755>26892F Datasheet

  Datasheet 13 pages · 685 KB · EN

  Infineon Technologies datasheet for model 755>26892F, providing specifications, package outline, revision details and legal disclaimer.

• Infineon BTS737S3 Smart High-Side Power Switch Datasheet

  Datasheet 15 pages · 279 KB · EN

  The Infineon BTS737S3 datasheet provides specifications, functional diagrams, pin definitions, ratings, and protection features for the four‑channel Smart…

• Infineon Technologies IPD06N03LA, IPF06N03LA, IPS06N03LA, IPU06N03LA Power-Transistor Datasheet

  Datasheet 12 pages · 420 KB · EN

  The Infineon Technologies datasheet provides specifications, electrical characteristics, thermal data, and package outlines for the IPD06N03LA, IPF06N03LA…
