Featured IDEAL INDUSTRIES manuals
Ideal Industries NaviTEK II Network Tester Product Leaflet
The NaviTEK II family provides technicians with a compact, handheld solution for troubleshooting active and passive Ethernet networks. It supports both copper and fibre links, detects PoE 802.3af services, and can quickly autotest the total number of devices on a network.
The product line includes several variants (NaviTEK II, PLUS, PRO, SignalTEK II, SignalTEK II FO) each supplied with accessories such as remote units, rechargeable power modules, patch cables, and a carrying case. Test results can be saved as XML files for Microsoft Excel, and the SignalTEK models add full‑gigabit bi‑directional load testing and compliance with IEEE 802.3ab.
Covers: Product Overview · Key Features · Model Variants · Included Accessories · Technical Specifications
IDEAL Industries InSITE®, NJX™, TLC™ & OmniConn™ Compression Connector Installation Guide
The document describes IDEAL Industries' range of compression connectors for coaxial cables used in HD video and security applications. It covers the InSITE®, NJX™, TLC™ and OmniConn™ families, highlighting features such as 360° clear windows, weather‑proof seals, and support for 23‑18 AWG solid center conductors.
Installation procedures, recommended tools (OmniSeal™ Pro XL, LinearX® series, PrepPRO® stripping tools) and cable‑preparation guidelines are detailed. Compatibility charts and part numbers help installers select the correct connector and tool for each cable type.
Covers: Compression Connector Installation Solutions · InSITE® Compression Connectors · F‑Compression Connectors · Compression Tools · Cable Preparation
IDEAL INDUSTRIES Custom Stripmaster® Wire Strippers Product Leaflet
The leaflet presents IDEAL INDUSTRIES' range of precision wire strippers, including the Custom Stripmaster®, Custom Stripmaster® Lite, Omega Stripmaster®, Ergo‑Elite Stripmaster® and the Stripmaster® 950. Each model offers V‑Notch cutting edges, lightweight designs, high‑visibility handles and replaceable blades for accurate stripping of 10‑30 AWG (or 16‑30 AWG for the Lite version).
These tools are targeted at aerospace and other high‑precision sectors where reliability and tight tolerances are critical. The document also mentions free wire‑analysis services, optional accessories, and the pneumatic Stripmaster® 950 machine that automatically strips 10‑30 AWG wire with electronic triggering.
Covers: CUSTOM STRIPMASTER® · CUSTOM STRIPMASTER® LITE · V‑NOTCH CUTTER · OMEGA STRIPMASTER® · ERGO‑ELITE STRIPMASTER® · STRIPMASTER® 950
Latest IDEAL INDUSTRIES manuals
Ideal Industries NaviTEK II Network Tester Product Leaflet
Product Leaflet 1 pages · 168 KB · ENThe Ideal Industries NaviTEK II series are versatile network testers for copper and fibre, offering PoE detection, autotest, and XML report generation.
IDEAL Industries InSITE®, NJX™, TLC™ & OmniConn™ Compression Connector Installation Guide
Installation Guide 8 pages · 2.6 MB · ENThis guide explains how to install IDEAL Industries' InSITE®, NJX™, TLC™ and OmniConn™ compression connectors, tools, and cable preparation.
IDEAL INDUSTRIES Custom Stripmaster® Wire Strippers Product Leaflet
Product Leaflet 2 pages · 997 KB · ENThe IDEAL INDUSTRIES Custom Stripmaster® leaflet details wire‑stripper models, features, specifications, and aerospace applications.
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in IDEAL INDUSTRIES manuals
What types of networks can the NaviTEK II test?
It can test both copper and fibre Ethernet networks, including 10/100 Mb and Gigabit Ethernet.
From: Ideal Industries NaviTEK II Network Tester Product Leaflet
Can test results be exported for analysis?
Yes, results can be saved as XML files for Microsoft Excel.
From: Ideal Industries NaviTEK II Network Tester Product Leaflet
What cable preparation size is required for IDEAL compression connectors?
All IDEAL compression connectors require a standard 1/4" × 1/4" cable preparation.
From: IDEAL Industries InSITE®, NJX™, TLC™ & OmniConn™ Compression Connector Installation Guide
Do the connectors have a weather‑proof seal?
Yes, the RTQ™ compression sleeve gives each connector a weather‑proof seal at the cable entry point.
From: IDEAL Industries InSITE®, NJX™, TLC™ & OmniConn™ Compression Connector Installation Guide
What wire gauge range does the Custom Stripmaster® handle?
It strips 10‑30 AWG solid or stranded wire.
From: IDEAL INDUSTRIES Custom Stripmaster® Wire Strippers Product Leaflet
How much hand pressure does the Custom Stripmaster® Lite require compared to the standard model?
The Lite version requires one‑third less hand pressure per strip actuation.
From: IDEAL INDUSTRIES Custom Stripmaster® Wire Strippers Product Leaflet
