Featured HiSilicon manuals
HiSilicon Hi3521DV200 H.265 Codec AI Processor Datasheet
The Hi3521DV200 is a system‑on‑chip designed for multi‑channel HD/4K DVR applications. It integrates a quad‑core ARM Cortex‑A7 CPU running at 1.2 GHz, 256 KB L2 cache, NEON/FPU support and a neural network inference engine (NNIE) delivering up to 0.8 Tops of compute for AI tasks such as face detection and object tracking.
The chip provides four MIPI D‑PHY video inputs, HDMI 1.4b, VGA, BT.656/BT.1120, CVBS outputs, as well as SATA, USB, UART, SPI, I2C and Ethernet interfaces. It supports H.265/H.264/JPEG encoding and decoding, multiple bitrate control modes, and includes security engines (AES, RSA, SHA, OTP, secure boot). Typical power consumption is 3.3 W and the package measures 19 mm × 19 mm, operating from 0 °C to 70 °C. This manual is written in Chinese.
Covers: Main Features · Video Interfaces · Peripheral Interfaces · Physical Specifications · Functional Block Diagram · Single‑chip DVR Solution
HiSilicon Hi3559V100 Mobile Camera SoC Datasheet
Hi3559V100 is a MobileCam™ intelligent video processor designed for professional cameras, high‑end drones, action cameras, 3D/VR cameras and dash cams. It combines a 5th‑gen Hi‑Lark video encoder, a 4th‑gen Hi‑ISP image processor, and a dual‑core A17+A7 CPU to deliver high‑resolution video and advanced image‑processing features.
Key features include 4K@30fps + 1080P@30fps H.265 encoding, dual‑sensor support up to 16 MP, USB 3.0/PCIe 2.0 high‑speed interfaces, HDR, 6‑DoF digital stabilization, and low‑power operation in a 10 mm × 10 mm FC‑CSP package. This manual is written in Chinese.
Covers: Product Overview · Key Features · Processor Cores · Video Encoding · Image Signal Processor · Video & Audio Interfaces
Latest HiSilicon manuals
HiSilicon Hi3521DV200 H.265 Codec AI Processor Datasheet
Datasheet 7 pages · 265 KB · ZHThe HiSilicon Hi3521DV200 is an H.265 codec AI processor with a quad‑core Cortex‑A7, NNIE inference engine and extensive video interfaces.
HiSilicon Hi3559V100 Mobile Camera SoC Datasheet
Datasheet 7 pages · 362 KB · ZHThe HiSilicon Hi3559V100 is a professional 2K/4K mobile camera SoC featuring dual‑sensor input, 4K30fps H.265 encoding, integrated dual‑core CPU, ISP, and…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in HiSilicon manuals
What is the maximum video output resolution of the Hi3521DV200?
Through its HDMI 1.4b interface the processor can output up to 3840 × 2160 at 30 fps.
From: HiSilicon Hi3521DV200 H.265 Codec AI Processor Datasheet
How much power does the chip consume during 4K30fps H.265 encoding?
Typical power consumption is about 1.25 W.
