Featured e2v manuals
e2v TS68020 HCMOS 32-bit Virtual Memory Microprocessor Datasheet
The TS68020 is a high‑performance 32‑bit microprocessor built with HCMOS technology. It provides a rich instruction set, 4‑Gbyte direct addressing, virtual‑memory support, and a co‑processor interface for 32‑bit floating‑point units. The device is offered in two hermetically sealed ceramic packages: a 114‑pin PGA and a 132‑pin CQFP.
The datasheet lists the electrical characteristics (supply voltage 5 V ± 10 %, clock frequencies 16.67‑25 MHz), thermal limits (operating temperature –55 °C to +125 °C, thermal resistance values), mechanical dimensions, and compliance with MIL‑STD‑883. Ordering information, handling precautions, and revision history are also included.
Covers: Introduction · Block Diagram · Pin Configuration · Signal Description · Detailed Specifications · Electrical Characteristics
e2v PC7448 PowerPC 7448 RISC Microprocessor Datasheet
The PC7448 is a 32‑bit PowerPC RISC microprocessor implementing the full PowerPC architecture, with a superscalar core, up to four instructions fetched per cycle, and integrated 1 MB L2 cache with ECC. It supports multiple bus and I/O voltage options and includes extensive vector and floating‑point units.
The manual contains detailed specifications such as core and I/O voltage ranges, maximum operating frequencies, temperature limits, cache sizes, pin layouts, package dimensions, and ordering information, along with revision history and system design guidelines. This manual is written in Chinese.
Covers: Features · Overview · Comparison with PC7447A and PC7447 · Electrical and Thermal Parameters · Pin Assignment · Package Description
Latest e2v manuals
e2v TS68020 HCMOS 32-bit Virtual Memory Microprocessor Datasheet
Datasheet 43 pages · 1.4 MB · ENThe e2v TS68020 is a 32‑bit HCMOS microprocessor with virtual memory, offering up to 25 MHz operation, 114‑pin PGA or 132‑pin CQFP packages, and detailed…
e2v PC7448 PowerPC 7448 RISC Microprocessor Datasheet
Datasheet 53 pages · 20.8 MB · ZHThis document provides features, electrical and thermal specifications, block diagram, pin assignment and package details for the e2v PC7448 PowerPC 7448…
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in e2v manuals
What clock frequencies does the TS68020 support?
The TS68020 can operate at 16.67 MHz, 20 MHz, or 25 MHz.
From: e2v TS68020 HCMOS 32-bit Virtual Memory Microprocessor Datasheet
What is the recommended supply voltage for the device?
A 5.0 V DC supply with a tolerance of ±10 % is specified.
From: e2v TS68020 HCMOS 32-bit Virtual Memory Microprocessor Datasheet
What is the core voltage for the PC7448?
The core voltage is 1.1 V ± 50 mV when running at 1250 MHz.
Which I/O voltage levels are supported?
The device supports I/O voltages of 1.5 V, 1.8 V, or 2.5 V with a ±5 % tolerance.
