Featured E.P.C manuals
EPC 220C/230 Encoder User Manual
The EPC 220C/230 encoders are through‑shaft, all‑metal devices offering orthogonal quadrature square‑wave outputs. The 220C model provides a fixed direction output, while the 230 model includes forward/reverse selection and a 6‑wire cable option.
The manual lists electrical and mechanical parameters such as input voltage, current limits, resolution, response frequency, maximum speed, and mounting dimensions, and includes wiring diagrams, accessory part numbers, and application guidance for speed feedback in motor control systems.
Covers: Design Features · Electrical Parameters · Mechanical Parameters · Environmental Parameters · Wiring Diagrams · Accessories
EPC PR-106A Product Leaflet
The EPC PR-106A is an air‑pressure control unit designed for high‑temperature, high‑heat or mildly acidic environments. It offers automatic and manual operation modes and can be integrated into various processing lines such as printing machines and cutters.
The leaflet lists detailed specifications, including air pressure of 400 mmH₂O, air flow of 504 /min, maximum pressure of 1.0 MPa, oil flow of 44 /min, oil capacity of 12 #, operating temperature range 0 °C to +50 °C, oil standard ISO‑VG46, voltage 220‑380 V AC 60 Hz, and a weight of 32 kg (oil excluded). Example operation procedures are also described. This manual is written in Japanese.
Covers: Specifications · Hydraulic Diagram · EPC System Operation Examples
Latest E.P.C manuals
EPC 220C/230 Encoder User Manual
User Manual 24 pages · 1.6 MB · ENThe EPC 220C/230 Encoder User Manual provides specifications, wiring diagrams, and installation instructions for the 220C and 230 series encoders.
EPC PR-106A Product Leaflet
Product Leaflet 2 pages · 1.4 MB · JAThe EPC PR-106A product leaflet provides key specifications such as air pressure, flow rates, oil capacity, voltage, and operating temperature.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in E.P.C manuals
What input voltage does the EPC 220C/230 encoder require?
It operates from a 5 V to 28 V DC supply.
How many pulses per revolution does the 220C model provide?
The 220C model provides up to 600 counts per revolution.
What is the maximum air pressure of the PR‑106A?
The maximum air pressure is 1.0 MPa.
What voltage range does the PR‑106A operate on?
It operates on 220‑380 V AC at 60 Hz.
