Key facts
- Manuals
- 2
- Languages
- EN
- Last added
- 2026-09-30
Featured Dodge manuals
Dodge Insert Selection Guide for Plastics – Ultrasert I, IV, Ultra‑Mold, and More
This guide details the full range of Dodge plastic fastening inserts, including Ultrasert I, Ultrasert IV, Ultra‑Mold, Standard Expansion, Miniature Inserts and specialty designs. Each insert type is described with its key features, recommended installation techniques (ultrasonic, heat, press‑in) and typical applications such as automotive, electrical and high‑temperature sealing.\n\nThe document also includes technical data tables with dimensions, thread sizes and performance values, as well as information on Dodge’s engineering support, certifications (ISO 9001, AS 9100, TS 16949, ISO 14001) and global capabilities. It serves as a reference for designers, purchasing engineers and service technicians selecting the appropriate insert for a given plastic material.
Covers: Insert Selection Guide · Ultrasert Series · Ultra‑Mold Series · Standard Expansion Inserts · Miniature Inserts · Technical Specifications
Dodge SAF-XT & SAFS Pillow Blocks Instruction Manual
This manual provides step‑by‑step instructions for inspecting, installing, and maintaining Dodge SAF‑XT and SAFS pillow blocks. It includes safety warnings, torque specifications, clearance measurements, and lubrication procedures for all listed sizes.
The document also lists replacement part numbers, recommended greasing intervals, maximum operating speeds, and allowable misalignment values, helping technicians ensure reliable long‑term service of the bearing assemblies.
Covers: Inspection · Installation · Torque Values · Grease Lubrication · Misalignment Limits · Maximum RPM
Latest Dodge manuals
Dodge Insert Selection Guide for Plastics – Ultrasert I, IV, Ultra‑Mold, and More
Product Leaflet 40 pages · 4.4 MB · ENThe Dodge Insert Selection Guide provides specifications, installation methods, and application information for Ultrasert, Ultra‑Mold and other plastic inserts.
Dodge SAF-XT & SAFS Pillow Blocks Instruction Manual
User Manual 8 pages · 639 KB · ENInstallation, maintenance and operation guide for Dodge SAF‑XT and SAFS pillow blocks covering all sizes from 1‑1/16" to 10‑1/2".
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Dodge manuals
How does the Screw‑Lock version of Ultrasert II help in vibration applications?
The Screw‑Lock Ultrasert II includes a reusable internal locking element that secures screws against vibration and allows periodic adjustment.
From: Dodge Insert Selection Guide for Plastics – Ultrasert I, IV, Ultra‑Mold, and More
What torque values are recommended for installing the pillow blocks?
The manual provides recommended torque values in Table 2, listed in foot‑pounds for each size.
From: Dodge SAF-XT & SAFS Pillow Blocks Instruction Manual
What is the maximum RPM for a 115/16" bearing?
The maximum permissible speed for a 115/16" bearing is 4 500 rpm.
From: Dodge SAF-XT & SAFS Pillow Blocks Instruction Manual
