ALTAI models by category
Featured ALTAI manuals
Altai ART2542 Optical Isolation Counter Card Hardware User Manual
The Altai ART2542 is a PC104‑bus data acquisition card with optical isolation and timing/counting functions. It provides nine independent 16‑bit decrement counters and supports six counting modes for applications such as electronic product testing, signal acquisition, process control, and servo control.
The manual includes a functional overview, hardware layout, connector definitions, installation guidance, register map, and warranty information, helping users install the card, configure the base address, and operate the counters safely within the specified temperature and voltage ranges. This manual is written in Chinese.
Covers: 功能概述 · 产品应用 · 光隔离定时计数功能 · 其它硬件指标 · 板卡尺寸 · 产品安装核对表
Latest ALTAI manuals
Altai ART2542 Optical Isolation Counter Card Hardware User Manual
User Manual 14 pages · 439 KB · ZHHardware user manual for the Altai ART2542 optical isolation counter card, covering specifications, installation, and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ALTAI manuals
What is the isolation voltage of the ART2542 card?
The isolation voltage is 2500 V.
From: Altai ART2542 Optical Isolation Counter Card Hardware User Manual
How many independent counters does the ART2542 provide?
It provides nine independent decrement counters.
From: Altai ART2542 Optical Isolation Counter Card Hardware User Manual
