Key facts
- Brand
- KEB-Size
- Model
- COMBIVERT S4
- Category
- Industrial Robot
- Documents
- 2
- Languages
- EN · DE
- Last added
- 2012-03-19
Start here
KEB COMBIVERT S4 Application Manual
The KEB COMBIVERT S4 application manual describes the complete setup and use of the servo‑control unit. It covers safety instructions, interference suppression, ambient conditions, technical data, and wiring options for various encoder and resolver interfaces.
Key sections include installation and connection guidelines, detailed parameter programming, functional descriptions of drive modes, and an annex of new functions introduced in version 3.0. The document is intended for engineers and technicians responsible for commissioning and maintaining the system.
KEB-Size COMBIVERT S4 specifications
| Operating temperature | -10 °C … +45 °C |
|---|---|
| Protection class | IP20 |
| Rated output current (size D) | 2.7 A |
| Maximum motor line length (size D) | 50 m |
| Mains supply phases | 3 phases |
All KEB-Size COMBIVERT S4 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What are the ambient temperature limits for operation?
The unit can operate between -10 °C and +45 °C.
What protection rating does the COMBIVERT S4 have?
It is rated IP20.
What is the operating temperature range of the COMBIVERT S4?
The drive can operate from –10 °C up to +45 °C.
What IP protection rating does the COMBIVERT S4 have?
It is rated IP20.
