The Xin Chao PCI-1632 user manual provides an overview, specifications, installation steps, programming guide and service information for the 32‑channel…
This manual describes the Xin Chao PCI-1632 high‑performance data acquisition board. It details the 32 analog input channels, programmable gain, optical isolation, and FPGA‑based control logic, suitable for medium‑speed, high‑precision measurement applications.
The document includes sections on hardware setup, driver installation, programming interfaces, API functions, and warranty service, offering end‑users and developers the information needed to operate and integrate the card. This manual is written in Chinese.
| Working voltage | 5 V ± 0.25 V |
|---|---|
| Power consumption | 5 V @ 250 mA (typical) |
| Operating temperature | 0 °C ~ 70 °C |
| Storage temperature | -10 °C ~ 85 °C |
| Humidity range | 5 % ~ 95 % |
Run the setup.exe file on the supplied CD, then insert the PCI‑1632 card; Windows will detect the hardware and prompt for driver installation.
The card supports bipolar input ranges of ±10 V, ±5 V, ±2.5 V, and ±1.25 V, selectable per channel.
Connect an external trigger signal to the EXT_TRIG pin; the card starts conversion on a falling‑edge trigger when configured for external trigger mode.
