ANALOG DEVICES AD5233 English products handbook Rev B

Update: 30 September, 2023

AD5233 is a quad 64-position digital potentiometer with nonvolatile memory from Analog Devices. It has 4-channel independent programmable 64-position resolution, 10 kΩ, 50 kΩ and 100 kΩ terminal resistance, permanent memory write protection, wipe setting readback, predefined linear increment/decrement instructions, predefined ±6 dB/step log taper increment/decrement instructions, SPI-compatible serial interface with readback function, 2.7 V to 5.5 V single supply or ±2.5 V dual supply and 11 bytes extra nonvolatile memory for user-defined data.

Brand: ANALOG

File format: PDF

Size: 769 KB

MD5 Checksum: 73FBEF9C94EA395956076E0F2FE4E9CE

Publication date: 09 May, 2012

Downloads: -

PDF Link: ANALOG DEVICES AD5233 English products handbook Rev B PDF

Download
