Featured Cosel manuals
Cosel LEA100F User Manual
This manual describes the Cosel LEA100F power supply, including its electrical ratings, dimensions, and compliance information. It is intended for users who need to install, configure, and safely operate the unit.
Key sections cover input voltage ranges, available output voltages and currents, safety guidelines, and certification details. The document also lists mechanical dimensions and environmental limits.
Covers: Product Overview · Electrical Ratings · Input Voltage Range · Output Voltage Options · Safety and Compliance
Cosel PBA100F Power Supply Manual
The PBA100F series from Cosel is a high‑voltage pulse‑type power supply offering multiple output voltage options for industrial applications. The manual lists the electrical ratings, protection features, and environmental limits for each model variant.
Key specifications include input voltage ranges of AC 85‑264 V or DC 120‑370 V, output voltages from 3.3 V to 48 V, maximum output power up to 108 W, and efficiency up to 84 %. Safety certifications such as UL60950‑1, C‑UL, EN60950‑1, EN50178 and compliance with DENAN standards are also detailed, along with mechanical shock and vibration limits. This manual is written in Chinese.
Covers: Specifications · Electrical Ratings · Efficiency · Protection Features · Safety Certifications · Environmental Conditions
Cosel PBA10F Power Supply User Manual
This manual covers the Cosel PBA10F family of isolated DC‑DC power modules, including the PBA10F‑5, PBA10F‑12 and PBA10F‑24 variants. It details electrical characteristics such as output voltage, current, power rating, input voltage range, efficiency and leakage current, as well as mechanical dimensions and mounting options.
Safety information, environmental operating limits, and certification compliance (UL, C‑UL, EN) are provided, together with guidance on optional accessories like DIN rail mounting, external covers and remote‑on/off control. The document also includes installation torque values and notes on derating for high‑temperature or high‑load conditions. This manual is written in Chinese.
Covers: Electrical Characteristics · Output Voltage and Current · Input Voltage Range · Safety and Certifications · Environmental Conditions · Mechanical Dimensions and Mounting
Latest Cosel manuals
Cosel LEA100F User Manual
User Manual 1 pages · 723 KB · ENThe Cosel LEA100F User Manual provides specifications, wiring details, and operating information for the LEA100F power supply.
COSEL LEA50F Manual
Cosel PBA100F Power Supply Manual
Datasheet 1 pages · 761 KB · ZHThe Cosel PBA100F Power Supply Manual provides specifications, electrical characteristics, and safety information for the PBA100F series.
Cosel PBA10F Power Supply User Manual
User Manual 9 pages · 1.9 MB · ZHThe Cosel PBA10F manual provides specifications, installation instructions, safety certifications and wiring details for the power supply series.
cosel power module Manual(1)
cosel power module Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Cosel manuals
What is the input voltage range of the LEA100F?
The LEA100F accepts an AC input voltage from 100 V to 200 V.
What output voltages are available?
The unit can provide output voltages such as 3.3 V, 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 30 V, and 48 V.
What input voltage range does the PBA100F support?
It supports AC 85‑264 V or DC 120‑370 V.
What output voltages are available for the PBA100F?
The unit can be set to 3.3 V, 5 V, 9 V, 12 V, 24 V, 36 V, or 48 V.
What is the maximum output power of the PBA10F‑5 model?
The PBA10F‑5 delivers up to 10 W of output power.
What safety certifications does the PBA10F have?
It complies with UL60950‑1, C‑UL, EN60950‑1 and EN50178 standards.
