Featured EFD manuals
EFD HP Series High-Pressure Dispensing Tool and Mikros Dispensing Pen Product Leaflet
The HP™ Series high‑pressure dispensing tool applies RTV silicones, epoxies, medical adhesives and other thick fluids through tips as small as 0.004" in diameter. It is designed for use with EFD air‑powered dispensers and can multiply the output of a standard 100 psi dispenser up to 7×, offering fast, fatigue‑free application.
The Mikros™ dispensing pen minimizes waste and improves fluid control for critical applications. It uses a disposable 0.25 cc fluid reservoir tip with 30, 32 or 33 gauge stainless‑steel dispensing needles, delivering consistent micro‑dot amounts of 2‑part epoxies, UV‑cure adhesives and other medium‑viscosity fluids.
Covers: Features and Benefits · Model Specifications · Replacement Parts · Special‑Purpose Dispensing Systems · Contact Information
EFD Dispense Valve System Selection Guide
The EFD Dispense Valve System Selection Guide assists users in choosing the right valve and reservoir for a given fluid and application. It provides cross‑reference tables that match fluids to recommended valve models, and then matches those valves to suitable reservoirs based on pressure and viscosity.
The guide also highlights key valve and controller features, such as adjustable flow, fail‑safe operation, and digital control options. For detailed assistance, users are encouraged to contact EFD sales or a Fluid Application Specialist.
Covers: Application Definitions · Valve Selector · Fluid & Valve Cross‑Reference · Reservoir Selector · Valve Features · Controller Features
Latest EFD manuals
EFD HP Series High-Pressure Dispensing Tool and Mikros Dispensing Pen Product Leaflet
Product Leaflet 1 pages · 97 KB · ENThe EFD HP Series high‑pressure dispensing tool and Mikros dispensing pen provide fast, fatigue‑free application of thick fluids with interchangeable tips…
EFD Dispense Valve System Selection Guide
Product Leaflet 4 pages · 307 KB · ENA guide to help select the appropriate EFD dispense valve system based on fluid type, application, and pressure requirements.
Engineered Fluid Dispensing User Guide
Questions answered in EFD manuals
What is the maximum pressure of the HP3cc dispensing tool?
It produces a maximum pressure of 700 psi.
From: EFD HP Series High-Pressure Dispensing Tool and Mikros Dispensing Pen Product Leaflet
What tip diameter can the HP tool achieve?
The tool can use tips as small as 0.004 inches in diameter.
From: EFD HP Series High-Pressure Dispensing Tool and Mikros Dispensing Pen Product Leaflet
Which valve model is recommended for microdot applications requiring tip sizes between 27 and 33 gauge?
Use valve model 741MD‑SS instead of 740V‑SS for those microdot applications.
What pressure range should be used for low viscosity fluids?
Specify the 0‑15 psi reservoir for low viscosity fluids.
