Key facts
- Manuals
- 3
- Languages
- ZH
- Last added
- 2012-04-10
Featured 焊王 manuals
Hanwang WSE-180A/WSE-250A/WSE-350A/WSE-250P/WSE-350P Welding Machine User Manual
The manual introduces the Hanwang WSE series welding machines, covering their main applications such as TIG/ARC welding of aluminum, stainless steel, titanium and other alloys, as well as general DC arc welding with electrodes. It lists the product models (WSE-180A, WSE-250A, WSE-350A, WSE-250P, WSE-350P) and the standards they meet.
Safety warnings, installation requirements, detailed specifications, component diagrams, wiring and circuit schematics, operating procedures, preventive maintenance, troubleshooting, and warranty information are all provided to help users operate the machines safely and keep them in good condition. This manual is written in Chinese.
Covers: Company Overview · Safety Warnings · Product Applications and Scope · Operating Conditions · Technical Specifications · Main Components
Hanwang WS-125A/160A/180A/200A/250A/315A SCR DC Argon Arc Welding Machine User Manual
The WS series consists of SCR‑controlled DC argon arc welding machines (WS‑125A, WS‑160A, WS‑180A, WS‑200A, WS‑250A, WS‑315A) designed for welding thin to medium‑thick steel, stainless steel, titanium, copper and alloys. They feature high‑frequency arc ignition, lightweight transformer, and precise current control.
This manual covers safety precautions, transport and storage conditions, detailed installation steps, wiring diagrams, panel descriptions, technical specifications, operation procedures for manual and argon‑arc modes, troubleshooting tables, warranty information and a packing list. This manual is written in Chinese.
Covers: Safety Warnings · Main Uses and Applicable Range · Specifications and Technical Parameters · Product Main Components · Electrical Diagrams · Installation, Connection and Testing
Hanwang KC-200A KC-350A KC-500A Welding Machine User Manual
This document introduces the Hanwang KC series gas‑shielded welding machines, describing their main applications, suitable work conditions, and technical specifications. It includes safety warnings, component descriptions, circuit diagrams, and detailed operating procedures.
Installation steps, wiring, grounding, and adjustment of welding parameters are covered, along with preventive maintenance, troubleshooting, and a warranty commitment. Appendices give welding‑parameter selection tables and explanations of name‑plate symbols. This manual is written in Chinese.
Covers: Company Introduction · Safety Warning · Product Main Uses and Scope · Working Conditions and Environment · Specifications and Technical Parameters · Main Components
Latest 焊王 manuals
Hanwang WSE-180A/WSE-250A/WSE-350A/WSE-250P/WSE-350P Welding Machine User Manual
User Manual 21 pages · 595 KB · ZHThis user manual provides safety guidelines, technical specifications, operation instructions, and maintenance procedures for Hanwang WSE series welding…
Hanwang WS-125A/160A/180A/200A/250A/315A SCR DC Argon Arc Welding Machine User Manual
User Manual 16 pages · 525 KB · ZHThe Hanwang WS series SCR DC argon arc welding machines manual provides safety warnings, installation, operation, specifications, and troubleshooting for…
Hanwang KC-200A KC-350A KC-500A Welding Machine User Manual
User Manual 16 pages · 456 KB · ZHThe manual provides safety warnings, specifications, installation, operation, and maintenance instructions for the Hanwang KC‑200A/350A/500A welding machines.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in 焊王 manuals
What is the input voltage requirement for the WSE-180A model?
The WSE-180A operates on single‑phase 220 V (±15 %) or 380 V (±15 %) supply.
From: Hanwang WSE-180A/WSE-250A/WSE-350A/WSE-250P/WSE-350P Welding Machine User Manual
How can I troubleshoot a no‑high‑frequency arc condition?
Check that the welding ground is properly connected, verify the gun‑to‑machine contact, ensure the tungsten tip is clean and close to the workpiece, and confirm the mains voltage is above 170 V (AC).
From: Hanwang WSE-180A/WSE-250A/WSE-350A/WSE-250P/WSE-350P Welding Machine User Manual
What safety precautions should be taken before using the welding machine?
The manual warns that the machine contains dangerous voltage, requires proper grounding, and that operators must wear protective clothing, eye protection, use ventilation, and avoid fire hazards, smoke, arc radiation and excessive noise.
From: Hanwang WS-125A/160A/180A/200A/250A/315A SCR DC Argon Arc Welding Machine User Manual
How should the welding machine be connected to the power supply?
Before connecting to the grid, the machine must be safely grounded by attaching a grounding wire to the grounding screw, then the power cable is connected firmly to the mains.
From: Hanwang WS-125A/160A/180A/200A/250A/315A SCR DC Argon Arc Welding Machine User Manual
What are the grounding requirements for the machine?
Connect the M8 grounding bolt on the rear panel to a protective earth using a cable of at least 8 mm², and ensure the connection complies with local electrical codes.
From: Hanwang KC-200A KC-350A KC-500A Welding Machine User Manual
