Featured ZGF-II manuals
ZGF II High Voltage Generator User Manual
The ZGF II series DC high‑voltage generator is a compact, lightweight device used by power utilities and industrial plants for DC withstand and leakage‑current testing of surge arresters, cables and high‑voltage equipment. It incorporates modern power‑electronics, PWM modulation, and MOSFET technology to deliver high output power with low ripple, and includes multiple protection functions such as over‑voltage, over‑current and zero‑position lock.
The manual provides safety guidelines, detailed wiring and grounding instructions, step‑by‑step operating procedures, adjustment of voltage and current settings, and troubleshooting tips. It also lists the accessories supplied with the unit and the technical specifications for various model variants. This manual is written in Chinese.
Covers: Overview · Working Principle · Performance Features · Technical Specifications · Operation Instructions · Safety and Maintenance
Latest ZGF-II manuals
ZGF II High Voltage Generator User Manual
User Manual 12 pages · 235 KB · ZHUser manual for the ZGF II series DC high‑voltage generator, covering safety, operation, specifications and maintenance.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ZGF-II manuals
What does the 0.75× voltage lock function do?
It locks the output voltage at 0.75 times the set value, allowing the voltage to be held steady for reference during testing.
