Featured XINTO manuals
XINTO TPM7 Direct-current Screen Monitor System Manual
The TPM7 system consists of seven direct‑current monitoring devices (TP760CT) together with a communication control unit (MCT001), AC monitoring module, DC monitoring module (MCT002) and various functional modules. It monitors dual‑channel AC voltage and current, bus voltage, battery pack voltage, discharge capacity and current, and provides 15 switch‑status inputs, battery management, alarm output, data storage, and background communication.
The manual describes hardware installation, parameter settings, communication configuration (RS485, MODBUS‑RTU, GPS), and maintenance procedures. It also details power supply options (DC220V, DC110V, DC48V), battery specifications (100 Ah, charge rates 0.1C/10 A, 1 A), and COM2 serial settings. This manual is written in Chinese.
Covers: System Overview · Hardware Components · Installation Procedure · Operation Instructions · Parameter Configuration · Communication Settings
Latest XINTO manuals
XINTO TPM7 Direct-current Screen Monitor System Manual
User Manual 7 pages · 268 KB · ZHThe XINTO TPM7 Direct‑current Screen Monitor System manual provides setup, operation, and configuration instructions for the TPM7 system.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in XINTO manuals
What DC voltage levels does the TPM7 system support?
It supports DC220V, DC110V, and DC48V power supplies.
From: XINTO TPM7 Direct-current Screen Monitor System Manual
Which communication interfaces are provided for the TPM7 system?
The system uses RS485 with MODBUS‑RTU protocol and also supports GPS communication.
From: XINTO TPM7 Direct-current Screen Monitor System Manual
