Featured Visonic manuals
Visonic NEXT DUO Digital Microwave Infrared Detector Installation Manual
The NEXT DUO is a digital microwave‑infrared detector that uses a micro‑processor to combine infrared and microwave sensing for reliable intrusion detection. It offers selectable detection ranges (6, 9, 12 m) and a patented True Motion Recognition algorithm to reduce false alarms. The unit operates on 9‑16 VDC and includes LED indicators for status and alarm conditions.
The manual provides step‑by‑step installation instructions, including mounting height (1.8‑2.4 m), wiring diagrams, pre‑heat time (60 s), and guidelines for avoiding interference from reflective surfaces. Safety notes, product limitations, and compliance information for FCC and European regulations are also included. This manual is written in Chinese.
Covers: Introduction · Technical Specifications · Installation · General Installation Guidelines · Installation Diagrams · Disclaimer
Latest Visonic manuals
Visonic NEXT DUO Digital Microwave Infrared Detector Installation Manual
Installation Guide 2 pages · 487 KB · ZHInstallation guide for the Visonic NEXT DUO dual‑technology digital microwave infrared detector, covering setup, wiring, and safety.
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in Visonic manuals
What is the maximum detection range of the NEXT DUO detector?
The detector can cover up to 12 meters in each direction.
From: Visonic NEXT DUO Digital Microwave Infrared Detector Installation Manual
At what height should the detector be mounted?
Mount the detector on a wall or corner at a height of 1.8 to 2.4 meters above the floor.
From: Visonic NEXT DUO Digital Microwave Infrared Detector Installation Manual
