Featured TECHSEM manuals
TECHSEM Y76DSH High-Speed Semiconductor Switch Datasheet
The Y76DSH is a large‑power, ultra‑fast semiconductor switch designed for high‑energy laser systems, nuclear physics research, and defense applications. It offers very high peak current capability and fast switching performance.
Key parameters include a voltage rating of 2500‑3000 V, forward peak current of 250 kA, reverse peak current of 1.5 kA, dv/dt of 1.0 kV/µs, di/dt of 60 kA/µs, and a turn‑on time of 250 µs. This manual is written in Chinese.
Covers: Features · Specifications · Outline
Latest TECHSEM manuals
TECHSEM Y76DSH High-Speed Semiconductor Switch Datasheet
Datasheet 1 pages · 120 KB · ZHThe TECHSEM Y76DSH high‑speed semiconductor switch datasheet provides key specifications such as voltage rating, peak currents, and switching speeds.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in TECHSEM manuals
What is the voltage rating of the Y76DSH switch?
The Y76DSH is rated for 2500 V to 3000 V.
From: TECHSEM Y76DSH High-Speed Semiconductor Switch Datasheet
What are the switching speed characteristics?
The device provides a dv/dt of 1.0 kV/µs, di/dt of 60 kA/µs, and a turn‑on time of 250 µs.
From: TECHSEM Y76DSH High-Speed Semiconductor Switch Datasheet
