Key facts
- Manuals
- 1
- Languages
- ZH
- Last added
- 2012-01-20
Featured TCN manuals
TCN Series Counter User Manual
This manual describes the features, technical parameters, wiring, and operation of the TCN series counters. It covers four‑digit (TCN‑P41A/P41B) and six‑digit (TCN‑P61A/P61B) models, their LED displays, and available output functions (F, N, R, C).\n\nSafety and usage notes are included, such as environmental limits, recommended input signal levels, and precautions to avoid damage to the device. The document also provides timing adjustments and panel button functions for setting delay and output modes. This manual is written in Chinese.
Covers: Features · Technical Parameters · Wiring and Connection · Operation Panel Description · Precautions and Environmental Limits · Timing and Output Settings
Latest TCN manuals
TCN Series Counter User Manual
User Manual 2 pages · 415 KB · ZHThe TCN series counter user manual provides specifications, operation instructions, and safety guidelines for TCN-P41A, P61A, P41B, and P61B models.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in TCN manuals
What is the power consumption of the TCN series counter?
The device consumes about 5 W of power.
What is the maximum counting speed?
The counter can operate up to 1000 counts per second.
