Gatal TAB9-8S PLC Display User Manual

The Gatal TAB9-8S is an 8‑digit BCD PLC display module. It provides basic functions such as digit display, customizable decimal points, and control of individual or all digits. The unit can be powered by either NPN or PNP transistor modules and supports various input configurations.

The manual describes the front panel layout, pin connector assignments, signal input connections, and power supply requirements. It also explains operation steps for setting digits, decimal points, and character displays using the function keys. This manual is written in Japanese.

Covers: Basic Functions · Operation Instructions · Front Panel Description · Pin Connector Description · Signal Input Connections · Power Supply
