Featured SR-E manuals
SR‑E Series Solar Charge Controller User Manual
The SR‑E series solar charge controller is designed for solar DC power systems, street‑light systems and small solar stations. It uses a microprocessor‑based control algorithm, offers five load‑working modes, and includes advanced commercial‑power switching, battery management, and multiple protections.
The document provides detailed installation steps, wiring diagrams, parameter settings, and a FAQ section that helps users diagnose common indicator‑light issues and protect the system from over‑charge, over‑discharge, overload, short‑circuit and reverse‑polarity conditions. This manual is written in Chinese.
Covers: Main Features · System Description · Installation and Use · Controller Panel Diagram · Operation Instructions · Parameter Description
Latest SR-E manuals
SR‑E Series Solar Charge Controller User Manual
User Manual 2 pages · 283 KB · ZHThe manual explains features, installation, operation modes and troubleshooting for the SR‑E series solar charge controller.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in SR-E manuals
What should I do if the solar panel indicator light is off under sunshine?
Check the photocell wiring and make sure the connection is correct and reliable.
Why does the battery indicator flash quickly without output?
The battery is over‑discharged; after it is recharged the controller will automatically resume operation.
